Joanneumite

Cu(C3N3O3H2)2(NH3)2
IMA status
  • Approved
IMA symbol
Joa
IMA approved
2012
Also known as
  • IMA2012-001
  • Joanneumiet

Where it forms, where it's found

Geological setting

Cracks in a gabbro covered by guano deposit with associated copper minerals

Type locality
Pabellón de Pica
  1. Chanabaya
  2. Iquique
  3. Iquique Province
  4. Tarapacá
  5. Chile

-20.9089°, -70.1381°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Violet
Streak
pale violet
Density
2.020 g/cm³

Optical

UV response
None

Crystallography

Crystal system
Triclinic
Space group
P-1
Cell parameters
a = 5.042(1) Å · b = 6.997(1) Å · c = 9.099(2) Å
Cell angles
α = 90.05(3) ° · β = 98.11(2) ° · γ = 110.95(3) °
Ratio a:b:c
1 : 1.388 : 1.805
Unit cell volume
290.8 ų
Z
1
Morphology

Microcrystalline aggregates up to 2 mm

Type-locality form

Microcrystalline aggregates up to 2 mm

Comment

Parameters for the synthetic analogue prepared for structure refinement: a=4.982, b=6.896, c=9.115, α=90.53, β=97.85, γ=110.08, V=290.8

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
7NNitrogenNitrogen814.007112.056
31.68%
8OOxygenOxygen615.99995.994
27.14%
6CCarbonCarbon612.01172.066
20.37%
29CuCopperCopper163.54663.546
17.96%
1HHydrogenHydrogen101.00810.080
2.85%
Total353.742100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • (Zn)

Synonyms

  • IMA2012-001
  • Joanneumiet

In other languages

German
IMA 2012-001 · Joanneumit
Italian
joanneumite
Japanese
ヨアネウム石

Classification

Strunz
10th ed.

10.CA.60

  • 10Organic CompoundsClass
  • 10.CMiscellaneous Organic MineralsDivision
  • 10.CAMiscellaneous Organic MineralsGroup
  • 10.CA.60JoanneumiteSpecies

Literature, links & citation

Citations
  1. 2012Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2012) New minerals and nomenclature modifications approved in 2012. CNMNC Newsletter No 13. Mineralogical Magazine, 76 (3) 807-817 doi:10.1180/minmag.2012.076.3.26 DOI: 10.1180/minmag.2012.076.3.26
  2. 2017(2017) Joanneumite. Handbook of Mineralogy. Mineralogical Society of America
  3. 2017Bojar, Hans-Peter, Walter, Franz, Baumgartner, Judith (2017) Joanneumite, Cu(C3N3O3H2)2(NH3)2, a new mineral from Pabellón de Pica, Chile and the crystal structure of its synthetic analogue. Mineralogical Magazine, 81 (1) 155-166 doi:10.1180/minmag.2016.080.078 DOI: 10.1180/minmag.2016.080.078
  4. 2023Košek, Filip, Němec, Ivan, Jehlička, Jan (2023) Raman study of several Cu‐bearing complex minerals from the guano deposit at Pabellón de Pica, Tarapaca region, Chile. Journal of Raman Spectroscopy, 54 (11) 1172-1182 doi:10.1002/jrs.6506DOI: 10.1002/jrs.6506
