Johachidolite

CaAlB3O7
IMA status
  • Approved
  • Grandfathered
IMA symbol
Jhd
Also known as
  • Johachidoliet

Where it forms, where it's found

Geological setting

Nepheline dikes traversing limestone.

Type locality
Sangpal-tong (Johachido)
  1. Changbaeng-myon
  2. Kilju County
  3. North Hamgyong Province
  4. North Korea
1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789107.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
vitreous
Transparency
Transparent
Colour
Colorless · white · pale yellow · light green
Streak
White
Cleavage

none

Fracture
Sub-Conchoidal
Density
3.4 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
1.712 – 1.726
Surface relief
High
Principal indices
nα 1.712 · nβ 1.717 · nγ 1.726
Pleochroism
Non-pleochroic
Dispersion
relatively strong r> v
Luminescence
pale blue to intense blue under SW UV
UV response
Intense blue fluorescence (UV) due to traces of REEs.
Michel-Lévy diagramhighlighted lineδ = 0.0140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]140 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation140 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#51
Cell parameters
a = 9.767(2) Å · b = 11.723(3) Å · c = 4.3718(5) Å
Ratio a:b:c
1 : 1.200 : 0.448
Unit cell volume
408.3 ų
Z
4
Morphology

Occurs as grains and lamellar masses.

Type-locality form

Grains and lamellar masses.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen715.999111.993
52.96%
20CaCalciumCalcium140.07840.078
18.95%
5BBoronBoron310.81032.430
15.33%
13AlAluminiumAluminium126.98226.982
12.76%
Total211.483100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Johachidoliet

In other languages

German
Johachidolith
Italian
Johachidolite
Japanese
上八洞石
Russian
Йохачидолит

Classification

Strunz
10th ed.

6.CC.05

  • 6BoratesClass
  • 6.CTriboratesDivision
  • 6.CCPhyllo-triboratesGroup
  • 6.CC.05JohachidoliteSpecies
Dana
8th ed.

24.05.03.01

  • 24Anhydrous BoratesClass
  • 24.05MiscellaneousType
  • 24.05.03— unnamed intermediate level —Group
  • 24.05.03.01JohachidoliteSpecies
CIM

10.1.16

  • 10Borates with other anionsClass
  • 10.1Borates with halideGroup
  • 10.1.16JohachidoliteSpecies

Literature, links & citation

Citations
  1. 1942Iwase, E., Saito, N. (1942) Johachidolite - a new mineral of hydrous fluoborate of sodium, calcium and aluminium. Scientific Papers of the Institute of Physical and Chemical Research, Tokyo: 39: 300-304.
  2. 1948Fleischer, M. (1948) New mineral names. American Mineralogist: 33: 98-100.
  3. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  4. 1968Davies, W. O., Machin, M. P. (1968) Johachidolite, a revised chemical formula. American Mineralogist, 53 (11-12) 2082-2083
  5. 1972Moore, P.B., Araki, T. (1972) Johachidolite, CaAl[B3O7], a borate with very dense atomic structure. Nature Physical Science: 240: 63-65.
