Joteite

Ca2CuAl(AsO4)[AsO3(OH)]2(OH)2 · 5H2O
IMA status
  • Approved
IMA symbol
Jot
IMA approved
2012
Also known as
  • IMA2012-091
  • Joteiet

Where it forms, where it's found

Geological setting

oxidized hydrothermal sulfide vein in volcanoclastic rocks

Type locality
Jote Mine
  1. Pampa Larga mining district
  2. Tierra Amarilla
  3. Copiapó Province
  4. Atacama
  5. Chile

-27.6086°, -70.1564°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Sky blue to greenish blue
Streak
pale blue
Tenacity
brittle
Cleavage
Perfect

(001)

Fracture
Sub-Conchoidal
Density
3.056 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 78°
Refractive index
1.634 – 1.651
Surface relief
Moderate
Principal indices
nα 1.634 · nβ 1.644 · nγ 1.651
Pleochroism
Weak

Z=Greenish blue > Y pale greenish blue > X colorless

Michel-Lévy diagramhighlighted lineδ = 0.0170
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]170 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation170 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 6.0530(2) Å · b = 10.2329(3) Å · c = 12.9112(4) Å
Cell angles
α = 87.572(2) ° · β = 78.480(2) ° · γ = 78.697(2) °
Ratio a:b:c
1 : 1.691 : 2.133
Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1915.999303.981
42.60%
33AsArsenicArsenic374.922224.766
31.50%
20CaCalciumCalcium240.07880.156
11.23%
29CuCopperCopper163.54663.546
8.91%
13AlAluminiumAluminium126.98226.982
3.78%
1HHydrogenHydrogen141.00814.112
1.98%
Total713.543100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2012-091
  • Joteiet

In other languages

German
IMA 2012-091 · Joteit
Italian
joteite

Classification

Strunz
10th ed.

8.DH.70

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DHWith large and medium-sized cations, (OH, etc.):RO4 < 1:1Group
  • 8.DH.70JoteiteSpecies

Literature, links & citation

Citations
  1. 2013Kampf, A. R., Mills, S. J., Housley, R. M., Rossman, G. R., Nash, B. P., Dini, M., Jenkins, R. A. (2013) Joteite, Ca2CuAl[AsO4][AsO3(OH)]2(OH)2·5H2O, a new arsenate with a sheet structure and unconnected acid arsenate groups. Mineralogical Magazine, 77 (6) 2811-2823 doi:10.1180/minmag.2013.077.6.08 DOI: 10.1180/minmag.2013.077.6.08
  2. 2015Belakovskiy, Dmitriy I., Cámara, Fernando, Gagne, Olivier C., Uvarova, Yulia (2015) New Mineral Names. American Mineralogist, 100 (8) 2005-2013 doi:10.2138/am-2015-nmn1008-98DOI: 10.2138/am-2015-nmn1008-98
  3. 2016(2016) Joteite. Handbook of Mineralogy. Mineralogical Society of America
