Julgoldite-(Fe2+)

Ca2Fe2+Fe3+2(Si2O7)(SiO4)(OH)2 · H2O
IMA status
  • Approved
IMA symbol
Jul-Fe2+
Also known as
  • Julgoldiet-(Fe2+)

Where it forms, where it's found

Geological setting

hematite-magnetite ore

Type locality
Långban Mine
  1. Långban Ore District
  2. Filipstad
  3. Värmland County
  4. Sweden

59.8554°, 14.2648°

16recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Deep black · greenish black to green in small fragments
Streak
Greenish olive with a bluish tinge
Tenacity
very brittle
Cleavage
Perfect

(100) and (001)

Density
3.58 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 50 – 70° · 2V calc = 73°
Refractive index
1.776 – 1.836
Surface relief
Very high
Principal indices
nα 1.776 · nβ 1.814 · nγ 1.836
Pleochroism
Strong

X = pale brown; Y = pale brownish green; Z = deep emerald-green.

Michel-Lévy diagramhighlighted lineδ = 0.0600
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]600 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation600 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 8.922(4) Å · b = 6.081(3) Å · c = 19.432(9) Å
Cell angles
β = 97.60(6) °
Ratio a:b:c
1 : 0.682 : 2.178
Z
4
Morphology

fan-shaped, plumose crystal groups; granular.

Twinning

Twin plane (001), typically repeated, common.

Comment

Space Group: A2/m:

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
40.00%
26FeIronIron355.845167.535
29.92%
14SiSiliconSilicon328.08584.255
15.05%
20CaCalciumCalcium240.07880.156
14.31%
1HHydrogenHydrogen41.0084.032
0.72%
Total559.964100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Julgoldiet-(Fe2+)

In other languages

German
IMA 1966-033 · Julgoldit-(Fe2+)
Italian
Julgoldite- · julgoldite-(Fe++) · julgoldite-(Fe2+)

Classification

Strunz
10th ed.

9.BG.20

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BGSorosilicates with mixed SiO4 and Si2O7 groups; cations in octahedral [6] and greater coordinationGroup
  • 9.BG.20Julgoldite-(Fe2+)Species
Dana
8th ed.

58.02.02.01

  • 58Sorosilicates Insular, Mixed, Single, and Larger Tetrahedral GroupsClass
  • 58.02Insular, Mixed, Single, and Larger Tetrahedral Groups with cations in [6] and higher coordination; single and double groups (n = 1, 2)Type
  • 58.02.02Pumpellyite groupGroup
  • 58.02.02.01Julgoldite-(Fe2+)Species
CIM

14.22.8

  • 14Silicates not Containing AluminumClass
  • 14.22Silicates of Fe and CaGroup
  • 14.22.8Julgoldite-(Fe2+)Species

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 1984Brastad, Kjartan (1984) Julgoldite from Tafjord, Sunnmøre. Contribution to the Mineralogy of Norway, No. 67. Norsk Geologisk Tidsskrift [Norwegian Journal of Geology], 64 (3) 251-255
  2. 1994Artioli, G., Geiger, C.A. (1994) The crystal chemistry of pumpellyite: An X-ray Rietveld refinement and 57Fe Mössbauer study. Physics and Chemistry of Minerals, 20 (7). 443-453 doi:10.1007/bf00203213DOI: 10.1007/bf00203213
  3. 2001(2001) Julgoldite-(Fe2+). Handbook of Mineralogy. Mineralogical Society of America
