Kaersutite

NaCa2(Mg3AlTi4+)(Si6Al2)O22O2
IMA status
  • Approved
IMA symbol
Krs
Discovered
1884
Also known as
  • Oxykaersutite

Where it forms, where it's found

Type locality
Østerfjeld
  1. Qaarsut
  2. Nuussuaq Peninsula
  3. Avannaata
  4. Greenland
263recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Translucent
Colour
Dark brown to black
Streak
Pale brownish-grey
Tenacity
brittle
Cleavage
Perfect

on (110)

Density
3.2 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 66 – 82° · 2V calc = 68 – 72°
Refractive index
1.67 – 1.772
Surface relief
High
Principal indices
nα 1.670 – 1.689 · nβ 1.690 – 1.741 · nγ 1.700 – 1.772
Pleochroism
Strong

X = yellow, yellow-brown; Y = red, red-brown; Z = deep brown, dark red-brown

Dispersion
r > v strong
Luminescence
Nonfluorescent
Michel-Lévy diagramhighlighted lineδ = 0.0565
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]565 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation565 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 9.89 Å · b = 18.06 Å · c = 5.31 Å
Cell angles
β = 105.41 °
Ratio a:b:c
1 : 1.826 : 0.537
Z
2
Twinning

Simple or multiple twinning parallel to (100)

Parting
partings on (100), (001)
Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2415.999383.976
44.79%
14SiSiliconSilicon628.085168.510
19.65%
13AlAluminiumAluminium326.98280.946
9.44%
20CaCalciumCalcium240.07880.156
9.35%
12MgMagnesiumMagnesium324.30572.915
8.51%
22TiTitaniumTitanium147.86747.867
5.58%
11NaSodiumSodium122.99022.990
2.68%
Total857.360100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Mn
  • K
  • F
  • H2O

Synonyms

  • Oxykaersutite

In other languages

French
Kaersutite
German
Kaersutit
Spanish
Kaersutita · kersutita
Italian
kaersutite
Japanese
ケルスート閃石
Chinese
钛角闪石 · 钛闪石

Classification

Strunz
10th ed.

9.DE.15

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DEInosilicates with 2-periodic double chains, Si4O11; ClinoamphibolesGroup
  • 9.DE.15KaersutiteSpecies
Dana
8th ed.

66.01.3a.18

  • 66Inosilicates Double-width, Unbranched Chains, (w=2)Class
  • 66.01Amphiboles - Mg-Fe-Mn-Li subgroupType
  • 66.01.3a— unnamed intermediate level —Group
  • 66.01.3a.18KaersutiteSpecies
CIM

16.14.4

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.14Aluminosilicates of Ti, Zr, Sn and PbGroup
  • 16.14.4KaersutiteSpecies

Group, growth & confusion

In the same group
1 members

Literature, links & citation

Citations
  1. 1961Wilkinson, J. F. G. (1961) Some aspects of the calciferous amphiboles, oxyhornblende, kaersutite and barkevikite. American Mineralogist, 46 (3-4) 340-354
  2. 1971Kitamura, M., Tokonami, M. (1971) The crystal structure of kaersutite. Sci. Rep Tohoku Univ., ser. 3: 11: 125-141.
  3. 1973Kitamura, M., Tokonami, M., Koto, K., Horiuchi, H., Morimoto, N. (1973) Cation ordering in kaersutite by neutron diffraction. Journal of the Mineralogical Society of Japan: 11: 49.
  4. 1973Hawthorne, F. C., Grundy, H. D. (1973) The crystal chemistry of the amphiboles II Refinement of the crystal structure of oxy-kaersutite. Mineralogical Magazine, 39 (304). 390-400 doi:10.1180/minmag.1973.039.304.02 DOI: 10.1180/minmag.1973.039.304.02
  5. 1975Kitamura, Masao, Tokonami, Masayasu, Morimoto, Nobuo (1975) Distribution of titanium atoms in oxy-kaersutite. Contributions to Mineralogy and Petrology, 51 (3) 167-172 doi:10.1007/bf00372077DOI: 10.1007/bf00372077
