Kambaldaite

NaNi4(CO3)3(OH)3 · 3H2O
IMA status
  • Approved
IMA symbol
Kbd
Discovered
1985
Also known as
  • IMA1982-098
  • Kambaldaiet

Where it forms, where it's found

Geological setting

Nickel sulfide deposit. A secondary mineral that has been precipitated on fracture surfaces in oxidizing Ni-Fe sulfide ore.

Type locality
Otter Shoot Nickel Mine
  1. Juan complex
  2. Kambalda Nickel mines
  3. Kambalda
  4. Coolgardie Shire
  5. Western Australia
  6. Australia

-31.1682°, 121.6532°

5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Emerald-green · bright grass green
Streak
Pale green
Cleavage
None Observed
Density
3.18 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.65 – 1.69
Surface relief
High
Principal indices
nω 1.65 · nε 1.69
Pleochroism
Strong

E : emerald green, and O : light green.

Michel-Lévy diagramhighlighted lineδ = 0.0400
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]400 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation400 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#104
Cell parameters
a = 10.340(3) Å · c = 6.097(2) Å
Unit cell volume
564.6 ų
Z
2
Morphology

Hexagonal prisms, generally terminated by basal pinacoids. Some crystals are terminated by second-order pyramids, together with small pinacoidal faces.

Type-locality form

Cryptocrystalline veins, layers and concretionary growths up to about 2 mm thick, commonly intergrown with gaspeite. Also as encrustations of tiny hexagonal prisms.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1515.999239.985
44.21%
28NiNickelNickel458.693234.772
43.25%
6CCarbonCarbon312.01136.033
6.64%
11NaSodiumSodium122.99022.990
4.23%
1HHydrogenHydrogen91.0089.072
1.67%
Total542.852100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1982-098
  • Kambaldaiet

In other languages

French
Kambaldaite
German
IMA 1982-098 · Kambaldait
Italian
Kambaldaite

Classification

Strunz
10th ed.

5.DA.20

  • 5CarbonatesClass
  • 5.DCarbonates with additional anions, with H2ODivision
  • 5.DAWith medium-sized cationsGroup
  • 5.DA.20KambaldaiteSpecies
Dana
8th ed.

16b.07.12.01

  • 16bHydrated Carbonates Containing Hydroxyl or HalogenClass
  • 16b.07MiscellaneousType
  • 16b.07.12— unnamed intermediate level —Group
  • 16b.07.12.01KambaldaiteSpecies
CIM

11.14.7

  • 11CarbonatesClass
  • 11.14Carbonates of Co and NiGroup
  • 11.14.7KambaldaiteSpecies

Literature, links & citation

Citations
  1. 1985Nickel, Ernest H., Robinson, Bruce W. (1985) Kambaldaite-a new hydrated Ni-Na carbonate mineral from Kambalda, Western Australia. American Mineralogist, 70 (3-4) 419-422
  2. 1985Engelhardt, Lutz M., Hall, Sydney R., White, Allan H. (1985) Crystal structure of kambaldaite, Na2Ni8(CO3)6(OH)6·6H2O. American Mineralogist, 70 (3-4) 423-427
  3. 2005(2005) Kambaldaite. Handbook of Mineralogy. Mineralogical Society of America
