Kasolite

Pb(UO2)(SiO4) · H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Kso
Discovered
1921
Also known as
  • Droogmansite

Where it forms, where it's found

Geological setting

Oxidation zone of uranium deposit.

Oxidation product of uraninite

Type locality
Shinkolobwe Mine
  1. Shinkolobwe
  2. Kambove Territory
  3. Haut-Katanga
  4. DR Congo

-11.0486°, 26.5508°

207recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789104 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent · Opaque
Colour
Ocher yellow to brownish yellow · amber brown · lemon yellow · to green or reddish orange
Streak
Pale yellow brown
Tenacity
brittle
Cleavage
Perfect

Perfect on (001) Indistinct on (100) (010)

Density
5.83 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 43° · 2V calc = 72°
Refractive index
1.89 – 1.95
Surface relief
Very high
Principal indices
nα 1.89 · nβ 1.91 · nγ 1.95
Pleochroism
Weak

X=Y= pale yellow Z= colorless to slightly grayish

Dispersion
strong
Michel-Lévy diagramhighlighted lineδ = 0.0600
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]600 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation600 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/a
Cell parameters
a = 13.24 Å · b = 6.94 Å · c = 6.70 Å
Cell angles
β = 104.33 °
Ratio a:b:c
1 : 0.524 : 0.506
Z
4
Morphology

Stout prismatic, lath-like crystals.

Type-locality form

Radiating needles, crystalline granular, and compact-massive.

Comment

"the structure is mechanically stable and very isotropic"

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium1238.029238.029
40.53%
82PbLeadLead1207.200207.200
35.28%
8OOxygenOxygen715.999111.993
19.07%
14SiSiliconSilicon128.08528.085
4.78%
1HHydrogenHydrogen21.0082.016
0.34%
Total587.323100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • As
  • P
  • Ba
  • Fe
  • Mg
  • Ca

Synonyms

  • Droogmansite

In other languages

French
kasolite
German
Kasolit
Spanish
Kasolita
Italian
kasolite
Russian
Казолит

Classification

Strunz
10th ed.

9.AK.15

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AKUranyl neso- and polysilicatesGroup
  • 9.AK.15KasoliteSpecies
Dana
8th ed.

53.03.01.01

  • 53Nesosilicates Insular Sio4 Groups and Other Anions or Complex CationsClass
  • 53.03Insular SiO4 Groups and Other Anions of Complex Cations with (UO2)Type
  • 53.03.01Uranophane groupGroup
  • 53.03.01.01KasoliteSpecies
CIM

14.16.17

  • 14Silicates not Containing AluminumClass
  • 14.16Silicates of UGroup
  • 14.16.17KasoliteSpecies

Group, growth & confusion

Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1921Schoep, A. (1921) Sur la kasolite, nouveau minéral radioactif. Comptes rendus hebdomadaires des séances de l'Académie des sciences de Paris: 173: 1476-1477 (in French). https://gallica.bnf.fr/ark:/12148/bpt6k31267/f1476.item
  2. 1922Wherry, E.T., Poitevin, E. (1922) New species. American Mineralogist: 7: 128-129.
  3. 1926Billiet, Valère (1926) Détermination des indices de réfraction de la becquerélite, de la curite, de la kasolite, de la fourmariérite, de la parsonsite, de la dumontite, et de l'ianthinite. Bulletin de la Société française de Minéralogie, 49 (3). 136-140 doi:10.3406/bulmi.1926.4309DOI: 10.3406/bulmi.1926.4309
  4. 1951Hogarth, D. D. (1951) Studies of radioactive compounds: II - Meta-zeunerite, uranophane, kasolite and cuprosklodowskite in Canada. American Mineralogist, 36 (5-6) 411-414
  5. 1963Huynen, A.M., Piret-Meunier, J., Van Meerssche, M. (1963) Structure de la kasolite. Académie Royale de Belgique, Classe des Sciences: 49: 192-201.
