Kiddcreekite

Cu6WSnS8
IMA status
  • Approved
IMA symbol
Kck
Discovered
1984
Also known as
  • IMA1982-106
  • Kiddcreekiet

Where it forms, where it's found

Geological setting

Massive sulfide deposit.

Type locality
Campbell Mine
  1. Bisbee
  2. Cochise County
  3. Arizona
  4. USA

31.4247°, -109.8903°

11recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Pale gray-brown · pale gray in reflected light
Density
4.934 g/cm³

Optical

Optical colour
Pale grey-brown to pale grey, sometimes with purplish tint.
Tropism
Isotropic
Reflectance R%
(22.7) 400, (23.2) 420, (23.6) 440, (23.7) 460, (23.3) 480, (22.6) 500, (22.1) 520, (22.5) 540, (23.3) 560, (23.9) 580, (24.1) 600, (24.0) 620, (23.7) 640, (23.2) 660, (22.6) 680, (22.2) 700
Reflected-light panel
23.2 %isotropic · single curve
Specimen sRGB 179, 122, 67
White reference100 % reflector under same lamp
Reflected colour
Pale grey-brown to pale grey, sometimes with purplish tint.

Crystallography

Crystal system
Isometric
Space group
#208
Cell parameters
a = 10.8178(3) Å
Unit cell volume
1265.95 ų
Z
4
Type-locality form

Irregular grains, as much as 100 µm across.

Comment

For type material, a = 10.856(2) A is given.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
29CuCopperCopper663.546381.276
40.55%
16SSulfurSulfur832.060256.480
27.28%
74WTungstenTungsten1183.840183.840
19.55%
50SnTinTin1118.710118.710
12.62%
Total940.306100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • V
  • Sb
  • Se

Synonyms

  • IMA1982-106
  • Kiddcreekiet

In other languages

German
IMA 1982-106 · Kiddcreekit
Italian
Kiddcreekite

Classification

Strunz
10th ed.

2.CB.35a

  • 2Sulfides and SulfosaltsClass
  • 2.CMetal Sulfides, M: S = 1: 1 (and similar)Division
  • 2.CBWith Zn, Fe, Cu, Ag, etc.Group
  • 2.CB.35aKiddcreekiteSpecies
Dana
8th ed.

02.09.06.02

  • 02SulfidesClass
  • 02.09AmBnXp, with (m+n):p = 1:1Type
  • 02.09.06— unnamed intermediate level —Group
  • 02.09.06.02KiddcreekiteSpecies
CIM

6.1.5

  • 6Sulphosalts - Sulphostannates, Sulphogermanates,Sulpharsenates, Sulphantimonates, Sulphovanadates and SulphohalidesClass
  • 6.1Sulphostannates and other sulfides containing SnGroup
  • 6.1.5KiddcreekiteSpecies

Literature, links & citation

Citations
  1. Jean Baptiste Labegorre. Synthèse et caractérisation de matériaux oxydes et oxylfures pour applications thermoélectriques.. Chimie organique. Normandie Université, 2018. Français.
  2. 1984Harris, D. C., Roberts, A. C., Thorpe, R. I., Criddle, A. J., Stanley, C. J. (1984) Kiddcreekite, a new mineral species from the Kidd Creek mine, Timmins, Ontario and from the Campbell orebody, Bisbee, Arizona. The Canadian Mineralogist, 22 (2) 227-232
  3. 2005(2005) Kiddcreekite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2014Liu, W., Dong, C., Gu, X. Liu, Yu, Qiu, X., Chen, Y. (2014): The crystal structure of kiddcreekite solved using micro X-ray diffraction and the EPCryst program. Mineralogical Magazine, 78, 1517–1525.
