Kinoite

Ca2Cu2Si3O10 · 2H2O
IMA status
  • Approved
IMA symbol
Kin
Discovered
1969
IMA approved
1969
Also known as
  • IMA1969-037

Where it forms, where it's found

Geological setting

Skarn and fault gouge.

Type locality
Kinoite type locality drill hole
  1. Helvetia-Rosemont Mining District
  2. Pima County
  3. Arizona
  4. USA

31.8500°, -110.7500°

21recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Deep blue
Cleavage
Very Good

excellent (010), distinct (001) and (100)

Density
3.13 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 68° · 2V calc = 64°
Refractive index
1.638 – 1.676
Surface relief
High
Principal indices
nα 1.638 · nβ 1.665 · nγ 1.676
Pleochroism
Strong

X= pale greenish blue Y= blue Z= deep blue

Dispersion
Relatively weak. Type description gives r < v, distinct.
Extinction
X = b, Z ∧ c ≃ 0°.
Notes

Absorption: Z > Y > X.

Michel-Lévy diagramhighlighted lineδ = 0.0380
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]380 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation380 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#15
Cell parameters
a = 6.99 Å · b = 12.88 Å · c = 5.65 Å
Cell angles
β = 96.18 °
Ratio a:b:c
1 : 1.843 : 0.808
Z
2
Morphology

Tabular in the plane of b and c axes. [hk0] zone is striated. Pseudoorthorhombic.

Type-locality form

Veinlets and crystals embedded in apophyllite. Euhedral crystals to 1mm. From drill core.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1215.999191.988
39.38%
29CuCopperCopper263.546127.092
26.07%
14SiSiliconSilicon328.08584.255
17.28%
20CaCalciumCalcium240.07880.156
16.44%
1HHydrogenHydrogen41.0084.032
0.83%
Total487.523100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mg

Synonyms

  • IMA1969-037

In other languages

French
Kinoite
German
IMA 1969-037 · Kinoit
Spanish
Kinoíta
Italian
Kinoite
Japanese
キノ石

Classification

Strunz
10th ed.

9.BH.10

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BHSorosilicates with Si3O10, Si4O11, etc. anions; cations in tetrahedral [4] and greater coordinationGroup
  • 9.BH.10KinoiteSpecies
Dana
8th ed.

57.01.02.01

  • 57Sorosilicates Si3o10 Groups and Larger Noncyclic GroupsClass
  • 57.01Insular Si3O10 and Larger Noncyclic Groups with [Si3O10] groupsType
  • 57.01.02— unnamed intermediate level —Group
  • 57.01.02.01KinoiteSpecies
CIM

14.2.9

  • 14Silicates not Containing AluminumClass
  • 14.2Silicates of CuGroup
  • 14.2.9KinoiteSpecies

Literature, links & citation

Citations
  1. 1970Anthony, John W., Laughon, Robert B. (1970) Kinoite, a new hydrous copper calcium silicate mineral from Arizona. American Mineralogist, 55 (5-6) 709-715
  2. 1971Laughon, Robert B. (1971) The crystal structure of kinoite. American Mineralogist, 56 (1-2) 193-200
  3. 1977Ruotsala, A.P., Wilson, M.L. (1977) Kinoite from Calumet, Michigan. American Mineralogist: 62(9-10): 1032-1033.
  4. 1977Wilson, M. L. (1977) Mineralogical Notes - Kinoite from Michigan - a New Occurrence, in California Issue!. The Mineralogical Record, 8 (6) 519-520
  5. 2001Kusachi, Isao, Nishimura, Makoto, Shiraga, Kanako, Kobayashi, Shoichi, Yamakawa, Junji (2001) Kinoite from Fuka, Okayama Prefecture, Japan. Journal of Mineralogical and Petrological Sciences, 96 (1) 29-33 doi:10.2465/jmps.96.29 DOI: 10.2465/jmps.96.29
