Kleberite

Fe3+Ti6O11(OH)5
IMA status
  • Approved
IMA symbol
Kbr
Also known as
  • IMA2012-023
  • Kleberiet

Where it forms, where it's found

Geological setting

Tertiary sands of Königshain.

Type locality
Kalimantan (Borneo)
  1. Indonesia
3recorded occurrences
Source · OpenStreetMap

Physical

Colour
Red-brown · orange · brown

Becomes orange when the Fe content decrease; yellow through red-brown to deep red in transmitted light.

Streak
Beige
Tenacity
brittle
Fracture
Irregular/Uneven
Density
3.28 g/cm³

Optical

Optical type
Uniaxial (-)
Surface relief
Very high
Principal indices
n 2.16
Birefringence
0.04-0.05
Dispersion
Locally biaxial (-) with 2V ~0; average n value given
Michel-Lévy diagramhighlighted lineδ = 0.0400
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]400 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation400 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 7.5259(6) Å · b = 4.5741(2) Å · c = 9.854(1) Å
Cell angles
β = 130.784(6) °
Ratio a:b:c
1 : 0.608 : 1.309
Type-locality form

Rounded grains, anhedral to euhedral, 0.04-0.3 mm.

Comment

Pseudohexagonal subcell (due to multiple twinning) with a = 2.845, c = 4.575 A (similar to pseudorutile which has a subcell with a = 2.866, c = 4.602 A) (Grey et al., 2013).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
22TiTitaniumTitanium647.867287.202
47.54%
8OOxygenOxygen1615.999255.984
42.38%
26FeIronIron155.84555.845
9.25%
1HHydrogenHydrogen51.0085.040
0.83%
Total604.071100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mg
  • (V)

Synonyms

  • IMA2012-023
  • Kleberiet

In other languages

German
IMA 2012-023 · Kleberit
Italian
Kleberite

Classification

Strunz
10th ed.

4.CB.25

  • 4OxidesClass
  • 4.CMetal: Oxygen = 2: 3,3: 5, and similarDivision
  • 4.CBWith medium-sized cationsGroup
  • 4.CB.25KleberiteSpecies
Dana
8th ed.

08.04.03

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.04A2B3O9Type
  • 08.04.03— unnamed intermediate level —Group
  • 08.04.03KleberiteSpecies

Group, growth & confusion

Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1960Dyadchenko, M.G., Khatuntseva, A.Ya. (1960) К минералогии и геохимии процесса выветривания иль’менита [On the mineralogy and geochemistry of the weathering process of ilmenite.]. Доклады Академии Наук СССР [Reports of the USSR Academy of Sciences.], 132 (2) 435-438
  2. 2006Steinike, K., Rohde, G., Bautsch, H. J. (2006) Zur Entdeckung des Minerals Kleberit. Mitteilungen der Deutschen Gesellschaft für Kristallographie e.V., 32. 15-18
  3. 2008Steinike, K., Kaemmel, Th. (2008) Kleberit – Pseudorutil/Hydroxyl-Pseudorutil – zwei Welten – zwei Namen – ein Mineral?. Geohistorischer Blätter, 11 (1-2) 1-8
  4. 2008Steinike, K. (2008) Die Entdeckungsgeschichte des Kleberits im nordöstlichen Teil Deutschlands (1949 - 1990 Staatsgebiet der DDR) Geohistorischer Blätter, 11 (1-2) 121-128
  5. 2012Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2012) New minerals and nomenclature modifications approved in 2012. CNMNC Newsletter No 14. Mineralogical Magazine, 76 (5) 1281-1288 doi:10.1180/minmag.2012.076.5.15DOI: 10.1180/minmag.2012.076.5.15
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Kleberite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/kleberite-10804},
  note      = {Accessed 2026-05-11}
}
