Kleinite

(Hg2N)(Cl,SO4) · nH2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Kle
Discovered
1905
Also known as
  • Kleiniet

Where it forms, where it's found

Type locality
Terlingua Mining District
  1. Texas
  2. USA
3recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Light to canary-yellow · orange · darkens to reddish yellow or orange in daylight and reverts to original color in darkness. Yellow to colourless in transmitted light.
Streak
Yellow
Tenacity
brittle
Cleavage
Distinct/Good

On (0001) easy but uneven; on (1010), imperfect.

Optical

Optical type
Uniaxial (+)
Refractive index
2.19 – 2.21
Surface relief
Very high
Principal indices
nω 2.19 · nε 2.21
Notes

Biaxial below 130°C (biaxial negative) and uniaxial above 130°C (uniaxial positive). Isotropic above aproximately 190°C.

Michel-Lévy diagramhighlighted lineδ = 0.0200
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]200 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation200 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#126
Cell parameters
a = 6.762(2) Å · c = 11.068(3) Å
Unit cell volume
438.3 ų
Z
4
Morphology

Crystals short prismatic [0001] with variable development of {10-11}; equidimensional at times. Crystals are anomalously birefringent - true symmetry may be monoclinic or triclinic, due to ordering of zeolitic chloride, sulfate and water, and. apparently hexagonal crystals may be highly twinned and/or pseudomorphs of truly hexagonal high-temperature polymorph (birefringence vanishes above 130°C).

Comment

data from Giester et al. (1996)

Crystal structure

Synonyms

  • Kleiniet

In other languages

French
Kleinite
German
Kleinit
Italian
Kleinite · Kleynite

Classification

Strunz
10th ed.

3.DD.35

  • 3HalidesClass
  • 3.DOxyhalides, hydroxyhalides and related double halidesDivision
  • 3.DDWith HgGroup
  • 3.DD.35KleiniteSpecies
Dana
8th ed.

10.04.03.01

  • 10Oxyhalides and HydroxyhalidesClass
  • 10.04A2(O,OH)XqType
  • 10.04.03— unnamed intermediate level —Group
  • 10.04.03.01KleiniteSpecies
CIM

26.16

  • 26Sulphates with HalideClass
  • 26.16— unnamed intermediate level —Group
  • 26.16KleiniteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1903Moses, A.J. (1903) Eglestonite, terlinguaite, and montroydite, new mercury minerals from Terlingua, Texas. American Journal of Science, Fourth Series: 16: 253-263. (as "yellow mercury mineral No. 5)
  2. 1905Sachs, A. (1905) Der Kleinit, ein hexagonales Quecksilberoxychlorid von Terlingua in Texas. Sitzungsberichte der Königlich Preussischen Akademie der Wissenschaften: 1905: 1091-1094.
  3. 1905Hillebrand, W.F. (1905) Preliminary announcement concerning a new mercury mineral from Terlingua, Texas. Science: 22(573): 844-844. (as mercurammonite)
  4. 1905Sachs, A. (1905) Akademie der Wissenschaften, Berlin, der Sitzungsberichte: 1091.
  5. 1906Hillebrand (1906) American Journal of Science: 21: 85.
