Kolicite

Zn4Mn2+7(AsO4)2(SiO4)2(OH)8
IMA status
  • Approved
IMA symbol
Kol
Discovered
1979
Also known as
  • IMA1978-076
  • Koliciet

Where it forms, where it's found

Geological setting

Marble-hosted zinc oxide and zinc silicate orebody.

Type locality
Sterling Mine
  1. Sterling Hill
  2. Ogdensburg
  3. Sussex County
  4. New Jersey
  5. USA

41.0836°, -74.6047°

2recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Red brown · orange
Streak
White, light orange
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
4.17 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 78° · 2V calc = 72°
Refractive index
1.779 – 1.79
Surface relief
High
Principal indices
nα 1.779 · nβ 1.786 · nγ 1.790
Birefringence
0.011
Pleochroism
Visible

X colorless to pale yellow, Y yellow orange, Z pale yellow

Dispersion
weak
Extinction
Parallel. XYZ = bca
UV response
Not fluorescent in UV
Michel-Lévy diagramhighlighted lineδ = 0.0110
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]110 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation110 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Cmca
Cell parameters
a = 18.59 Å · b = 8.789 Å · c = 12.04 Å
Ratio a:b:c
1 : 0.473 : 0.648
Z
4
Morphology

Nearly equant to blocky prismatic

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
25MnManganeseManganese754.938384.566
30.91%
8OOxygenOxygen2415.999383.976
30.86%
30ZnZincZinc465.380261.520
21.02%
33AsArsenicArsenic274.922149.844
12.04%
14SiSiliconSilicon228.08556.170
4.52%
1HHydrogenHydrogen81.0088.064
0.65%
Total1244.140100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Mg
  • H2O

Synonyms

  • IMA1978-076
  • Koliciet

In other languages

German
IMA 1978-076 · Kolicit
Italian
Kolicite

Classification

Strunz
10th ed.

8.BE.60

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BEWith only medium-sized cations, (OH, etc.):RO4 > 2:1Group
  • 8.BE.60KoliciteSpecies
Dana
8th ed.

43.04.08.01

  • 43Compound Phosphates, Etc.Class
  • 43.04Anhydrous Compound Phosphates, etc·, Containing Hydroxyl or HalogenType
  • 43.04.08— unnamed intermediate level —Group
  • 43.04.08.01KoliciteSpecies
CIM

17.7.14

  • 17Silicates Containing other AnionsClass
  • 17.7Silicates with vanadate, arsenate or antimonateGroup
  • 17.7.14KoliciteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. Obituary of John A. Kolic, October 9, 2014, New Jersey Herald.
  2. 1979Dunn, Pete J., Peacor, Donald R., Sturman, B. Darko (1979) Kolicite, a new manganese zinc silicate arsenate from Sterling Hill, Ogdensburg, New Jersey. American Mineralogist, 64 (7-8). 708-712
  3. 1980Peacor, Donald R. (1980) The crystal structure of kolicite, Mn7(OH)4[As2Zn4Si2O16(OH)4]. American Mineralogist, 65 (5-6) 483-487
  4. 1980Wilson, Wendell E. (1980) Abstracts of New Mineral Descriptions. The Mineralogical Record, 11 (2) 111-112
  5. 2001(2001) Kolicite. Handbook of Mineralogy. Mineralogical Society of America
