Kosnarite

KZr2(PO4)3
IMA status
  • Approved
IMA symbol
Ksn
Discovered
1991
Also known as
  • IMA1991-022
  • Kosnariet

Where it forms, where it's found

Geological setting

Secondary mineral in a complex granite pegmatite.

Late alteration mineral in granitic pegmatites.

Type locality
Black Mountain Quarry
  1. Rumford
  2. Oxford County
  3. Maine
  4. USA

44.5853°, -70.6464°

7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Pale blue to pale green to colourless.
Streak
White
Tenacity
brittle
Cleavage
Perfect

on (1012)

Fracture
Conchoidal
Density
3.194 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.656 – 1.682
Surface relief
High
Principal indices
nω 1.656 · nε 1.682
Michel-Lévy diagramhighlighted lineδ = 0.0260
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]260 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation260 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#98
Cell parameters
a = 8.7205(1) Å · c = 23.9436(3) Å
Unit cell volume
1576.89 ų
Z
6
Morphology

Rhombohedral pseudocubic crystals

Comment

Cell parameters from Piilonen et al. 2020.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1215.999191.988
37.91%
40ZrZirconiumZirconium291.224182.448
36.02%
15PPhosphorusPhosphorus330.97492.922
18.35%
19KPotassiumPotassium139.09839.098
7.72%
Total506.456100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Na
  • Rb
  • Mn
  • Hf
  • F

Synonyms

  • IMA1991-022
  • Kosnariet

In other languages

German
IMA 1991-022 · Kosnarit
Italian
Kosnarite

Classification

Strunz
10th ed.

8.AC.60

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ACWith medium-sized and large cationsGroup
  • 8.AC.60KosnariteSpecies
Dana
8th ed.

38.04.12.01

  • 38Anhydrous Normal Phosphates, Arsenates, and VanadatesClass
  • 38.04AXO4Type
  • 38.04.12— unnamed intermediate level —Group
  • 38.04.12.01KosnariteSpecies

Literature, links & citation

Citations
  1. 1969Šljukić, M.; Matković, B.; Prodić, B.; Anderson, D. (1969) The crystal structure of KZr2(PO4)3. Zeitschrift für Kristallographie, 130 (1-6). 148-161 doi:10.1524/zkri.1969.130.1-6.148 DOI: 10.1524/zkri.1969.130.1-6.148
  2. 1993Brownfield, Michael E., Foord, Eugene E., Sutley, Stephen J., Botinelly, Theodore (1993) Kosnarite, KZr2(PO4)3 a new mineral from Mount Mica and Black Mountain, Oxford County, Maine. American Mineralogist, 78 (5-6) 653-656
  3. 1994Birch, William D., Pring, Allan, Bevan, D. J. M., Kharisun, (1994) Wycheproofite: a new hydrated sodium aluminium zirconium phosphate from Wycheproof, Victoria, Australia, and a new occurrence of kosnarite. Mineralogical Magazine, 58 (393) 635-639 doi:10.1180/minmag.1994.058.393.13 DOI: 10.1180/minmag.1994.058.393.13
  4. 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
  5. 2005(2005) Kosnarite. Handbook of Mineralogy. Mineralogical Society of America
