Kuliokite-(Y)

Y4Al(SiO4)2(OH)2F5
IMA status
  • Approved
IMA symbol
Klo-Y
Also known as
  • IMA1984-064
  • Kuliokiet-(Y)

Where it forms, where it's found

Geological setting

amazonitic pegmatite

Type locality
Ploskaya Mountain
  1. Western Keivy Massif
  2. Keivy Mountains
  3. Lovozersky District
  4. Murmansk Oblast
  5. Russia

67.6333°, 36.7000°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colorless
Streak
white
Cleavage
Poor/Indistinct

(010)

Density
4.3 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 19 – 29° · 2V calc = 28°
Refractive index
1.656 – 1.703
Surface relief
High
Principal indices
nα 1.656 · nβ 1.700 · nγ 1.703
Dispersion
r > v
Extinction
Z = c; X ∧ a = 7°; Y ∧ b = 28°.
UV response
Yellow-green cathodoluminescence.
Michel-Lévy diagramhighlighted lineδ = 0.0470
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]470 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation470 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 4.3213(1) Å · b = 14.8123(6) Å · c = 8.6857(3) Å
Cell angles
β = 102.872(4) °
Ratio a:b:c
1 : 3.428 : 2.010
Z
2
Twinning

Polysynthetic.

Type-locality form

White crusts on fluorite.

Comment

space group Im

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
39YYttriumYttrium488.906355.624
51.11%
8OOxygenOxygen1015.999159.990
23.00%
9FFluorineFluorine518.99894.990
13.65%
14SiSiliconSilicon228.08556.170
8.07%
13AlAluminiumAluminium126.98226.982
3.88%
1HHydrogenHydrogen21.0082.016
0.29%
Total695.772100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1984-064
  • Kuliokiet-(Y)

In other languages

French
Kuliokite- · Kuliokite-(Y)
German
IMA 1984-064 · Kuliokit-(Y)
Italian
Kuliokite- · Kuliokite-(Y)

Classification

Strunz
10th ed.

9.AG.50

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AGNesosilicates with additional anions; cations in > [6] +- [6] coordinationGroup
  • 9.AG.50Kuliokite-(Y)Species
Dana
8th ed.

78.07.08.01

  • 78Unclassified SilicatesClass
  • 78.07Unclassified silicates wholly unclassified silicatesType
  • 78.07.08— unnamed intermediate level —Group
  • 78.07.08.01Kuliokite-(Y)Species
CIM

17.2.8

  • 17Silicates Containing other AnionsClass
  • 17.2Silicates with fluorideGroup
  • 17.2.8Kuliokite-(Y)Species

Literature, links & citation

Citations
  1. 1986Sokolova, E.V., Egorov-Tismenko, Y.K., Voloshin, A.V., Pakhomovskii, Y.A. (1986) Crystal structure of the new Y-Al silicate kuliokite-(Y), Y4Al[SiO4]2(OH)2F5. Soviet Physics - Doklady, 31, 601-603.
  2. 1986Voloshin, A.V., Pakhomovskii, Ya.A. (1986) Minerals and mineral formation evolution in amazonite pegmatites of Kola peninsula, - Leningrad, Nauka, 1986, 168.
  3. 1986Egorov-Tismenko, Y.K., Sokolova, E.V., Voloshin, A.V. (1986) Essays on structural mineralogy. IV. The crystal chemistry of kuliokite-(Y), Y4Al[SiO4]2(OH)2F5, and related compounds. Mineralogicheskii Sbornik, 40, 13-18.
  4. 1986Voloshin, A.V., Pakhomovsky, Y. A., Tyusheva, F. N., Sokolova, Y. V., Egorov-Tismenko, Y. K. (1986) Кулиокит-(Y) - новый иттрий-алюминиевый фторсиликат из амазонитовых пегматитов Кольского полуострова [Kuliokite-(Y) - A new yttrium-aluminium fluoride-silicate from amazonite pegmatites of the Kola Peninsula]. Mineralogiceskij Zhurnal, 8. 94-99
  5. 1988Hawthorne, Frank C., Burke, Ernst A. J., Ercit, T. Scott, Grew, Edward S., Grice, Joel D., Jambor, John L., Puziewicz, Jacek, Roberts, Andrew C., Vanko, David A. (1988) New Mineral Names. American Mineralogist, 73 (1-2) 189-199
