Kvanefjeldite

Na4CaSi6O14(OH)2
IMA status
  • Approved
IMA symbol
Kva
Discovered
1984
Also known as
  • IMA1982-079
  • Kvanefjeldiet

Where it forms, where it's found

Geological setting

Alkaline intrusive complex

Type locality
Kvanefjeld adit
  1. Kvanefjeld deposit
  2. Kuannersuit Plateau (Kvanefjeld)
  3. Ilímaussaq complex
  4. Kujalleq
  5. Greenland

60.9699°, -45.9929°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Pink with a distinct violet hue
Cleavage
Distinct/Good

Good on f010g; poor on (101)

Density
2.55 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 9°
Refractive index
1.522 – 1.543
Surface relief
Moderate
Principal indices
nα 1.522 · nβ 1.522 · nγ 1.543
Dispersion
r < v distinct
Michel-Lévy diagramhighlighted lineδ = 0.0210
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]210 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation210 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 10.213(2) Å · b = 15.878(4) Å · c = 9.058(1) Å
Ratio a:b:c
1 : 1.555 : 0.887
Z
4
Type-locality form

Streaks and veinlets

Comment

Space Group: Pcab

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1615.999255.984
45.83%
14SiSiliconSilicon628.085168.510
30.17%
11NaSodiumSodium422.99091.960
16.46%
20CaCalciumCalcium140.07840.078
7.18%
1HHydrogenHydrogen21.0082.016
0.36%
Total558.548100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Al
  • Y
  • Fe
  • Mg
  • K

Synonyms

  • IMA1982-079
  • Kvanefjeldiet

In other languages

German
IMA 1982-079 · Kvanefjeldit
Italian
Kvanefjeldite

Classification

Strunz
10th ed.

9.DP.30

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DPTransitional ino-phyllosilicate structuresGroup
  • 9.DP.30KvanefjelditeSpecies
Dana
8th ed.

72.05.03.01

  • 72Phyllosilicates Two-dimensional Infinite Sheets with Other Than Six-membered RingsClass
  • 72.05Two-Dimensional Infinite Sheets with Other Than Six-Membered Rings with corrugated and complex layersType
  • 72.05.03— unnamed intermediate level —Group
  • 72.05.03.01KvanefjelditeSpecies
CIM

14.18.28

  • 14Silicates not Containing AluminumClass
  • 14.18Silicates of Mn and Na, K, Mg, Ca or FeGroup
  • 14.18.28KvanefjelditeSpecies

Literature, links & citation

Citations
  1. 1983Johnsen, O., Leonardsen, E.S., Faelth, L., Annehed, H. (1983) Crystal structure of kvanefjeldite: The introduction of 2(Si3O7OH) layers with eight-membered rings. Neues Jahrbuch für Mineralogie, Monatshefte: 1983: 505-512.
  2. 1984Petersen, Ole V., Johnsen, Ole, Leonardsen, Erik S., Ronsbo, Jorn G. (1984) Kvanefjeldite, a new mineral species from the Ilimaussaq alkaline complex, Southwest Greenland. The Canadian Mineralogist, 22 (3) 465-467
  3. 1985Dunn, Pete J., Fleischer, Michael, Langley, Richard H., Shigley, James E., Zilczer, Janet A. (1985) New mineral names. American Mineralogist, 70 (7-8) 871-881
  4. 2001(2001) Kvanefjeldite. Handbook of Mineralogy. Mineralogical Society of America
