Långbanshyttanite

Pb2Mn2Mg(AsO4)2(OH)4 · 6H2O
IMA status
  • Approved
IMA symbol
Lbs
Also known as
  • IMA2010-071
  • Långbanshyttaniet

Where it forms, where it's found

Geological setting

Crystallized during the last stage of hydrothermal activity involving metal remobilization, and post-dating regional metamorphism of the volcanic-hydrothermal ores and their host rocks. It formed in fractures and corrosion veinlets, post-dating calcite, in a Mn-oxide-bearing, Mn-silicate-rich rock. A very late, low-temperature (prob below 70 °C) species.

Type locality
Långban Mine
  1. Långban Ore District
  2. Filipstad
  3. Värmland County
  4. Sweden

59.8554°, 14.2648°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Transparency
Transparent
Colour
Colourless
Streak
White
Tenacity
brittle
Cleavage
Perfect

On (001)

Density
3.951 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = ~90° · 2V calc = 86°
Refractive index
1.7 – 1.792
Surface relief
High
Principal indices
nα 1.700 · nβ 1.741 · nγ 1.792
Pleochroism
Non-pleochroic
Dispersion
Strong, r < v.
UV response
Not fluorescent
Notes

Orientation: X ≈ c, the angle between Z and elongation direction is 16°.

Michel-Lévy diagramhighlighted lineδ = 0.0920
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]920 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation920 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 5.0528(10) Å · b = 5.7671(6) Å · c = 14.617(3) Å
Cell angles
α = 85.656(14) ° · β = 82.029(17) ° · γ = 88.728(13) °
Ratio a:b:c
1 : 1.141 : 2.893
Unit cell volume
420.6 ų
Z
1
Type-locality form

Unoriented, felty to distinctly radial, hemispherical white aggregates up to 1 mm in size composed of acicular, lath-like crystals.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead2207.200414.400
41.33%
8OOxygenOxygen1815.999287.982
28.73%
33AsArsenicArsenic274.922149.844
14.95%
25MnManganeseManganese254.938109.876
10.96%
12MgMagnesiumMagnesium124.30524.305
2.42%
1HHydrogenHydrogen161.00816.128
1.61%
Total1002.535100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2010-071
  • Långbanshyttaniet

In other languages

German
IMA 2010-071 · Långbanshyttanit
Spanish
Longbanshyuttanita
Italian
långbanshyttanite

Classification

Strunz
10th ed.

8.DL.30

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DLWith large and medium-sized cations, (OH, etc.):RO4 = 2:1Group
  • 8.DL.30LångbanshyttaniteSpecies

Literature, links & citation

Citations
  1. 2011Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2011) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) Newsletter 8. Mineralogical Magazine, 75 (2) 289-294 doi:10.1180/minmag.2011.075.2.289 DOI: 10.1180/minmag.2011.075.2.289
  2. 2011Chukanov, Nikita V., Pekov, Igor V., Jonsson, Erik, Zubkova, Natalia V., Filinchuk, Yaroslav E., Belakovskiy, Dmitriy I., Pushcharovsky, Dmitry Y.U. (2011) Långbanshyttanite, a new low-temperature arsenate mineral with a novel structure from Långban, Sweden. European Journal of Mineralogy, 23 (4) 675-681 doi:10.1127/0935-1221/2011/0023-2120 DOI: 10.1127/0935-1221/2011/0023-2120
  3. 2012Tait, K. T. (2012) New Mineral Names. American Mineralogist, 97 (4) 759-761 doi:10.2138/am.2012.593DOI: 10.2138/am.2012.593
  4. 2015(2015) Långbanshyttanite. Handbook of Mineralogy. Mineralogical Society of America
