Laplandite-(Ce)

Na4CeTiPSi7O22 · 5H2O
IMA status
  • Approved
IMA symbol
Lpl-Ce
Also known as
  • IMA1974-005
  • Laplandiet-(Ce)

Where it forms, where it's found

Geological setting

Natrolite zone of a pegmatite in a differentiated alkalic massif.

Type locality
Yubileinaya pegmatite
  1. Karnasurt Mountain
  2. Lovozersky District
  3. Murmansk Oblast
  4. Russia

67.8833°, 34.6333°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Gray-white · pale yellow · pale blue
Fracture
Splintery
Density
2.83 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 28° · 2V calc = 26°
Refractive index
1.568 – 1.585
Surface relief
Moderate
Principal indices
nα 1.568 · nβ 1.584 · nγ 1.585
Dispersion
r > v strong
Michel-Lévy diagramhighlighted lineδ = 0.0170
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]170 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation170 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Pmmm
Cell parameters
a = 7.27 Å · b = 14.38 Å · c = 22.25 Å
Ratio a:b:c
1 : 1.978 : 3.061
Z
4
Morphology

Radial-fibrous aggregates.

Type-locality form

Radiating-fibrous deposits up to 0.5-1 cm and fan-shaped platy aggregates; the plates about 0.01 mm thick are flattened on the c axis.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2715.999431.973
45.49%
14SiSiliconSilicon728.085196.595
20.70%
58CeCeriumCerium1140.116140.116
14.76%
11NaSodiumSodium422.99091.960
9.69%
22TiTitaniumTitanium147.86747.867
5.04%
15PPhosphorusPhosphorus130.97430.974
3.26%
1HHydrogenHydrogen101.00810.080
1.06%
Total949.565100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1974-005
  • Laplandiet-(Ce)

In other languages

German
IMA 1974-005 · Laplandit-(Ce)
Spanish
Laplandita- · Laplandita-(Ce)
Italian
Laplandite- · Laplandite-(Ce)

Classification

Strunz
10th ed.

9.DJ.10

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DJInosilicates with 4-periodic double and triple chainsGroup
  • 9.DJ.10Laplandite-(Ce)Species
Dana
8th ed.

78.07.09.01

  • 78Unclassified SilicatesClass
  • 78.07Unclassified silicates wholly unclassified silicatesType
  • 78.07.09— unnamed intermediate level —Group
  • 78.07.09.01Laplandite-(Ce)Species
CIM

17.6.10

  • 17Silicates Containing other AnionsClass
  • 17.6Silicates with phosphateGroup
  • 17.6.10Laplandite-(Ce)Species

Literature, links & citation

Citations
  1. 1974Es’kova, E.M., Semenov, E.I., Khomyakov, A.P., Kazakova, M.E., Sidorenko, O.V. (1974) Laplandite, a new mineral. Zapiski Vsesoyuznogo Mineralogicheskogo Obshchestva: 103(5): 571-575.
  2. 1975Fleischer, Michael; Chao, G. Y.; Kato, Ikiro (1975) New Mineral Names. American Mineralogist, 60 (5-6). 485-489
  3. 2001(2001) Laplandite-(Ce). Handbook of Mineralogy. Mineralogical Society of America
