Launayite

CuPb10(Sb,As)13S30
IMA status
  • Approved
IMA symbol
Lau
Discovered
1966
IMA approved
1966
Also known as
  • IMA1966-021
  • Launayiet

Where it forms, where it's found

Geological setting

Marble.

Type locality
Taylor Pit
  1. Madoc
  2. Centre Hastings Municipality
  3. Hastings County
  4. Ontario
  5. Canada

44.5022°, -77.4664°

5recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Lead-gray
Streak
Black
Cleavage
Perfect

(100) and (001)

Fracture
Fibrous
Density
5.83 g/cm³

Optical

Pleochroism
Strong

White to gray

Anisotropism
Strong
Tropism
Anisotropic
Reflectance R%
(42.6,38.6) 470, (43.8,36.9) 546, (42.7,36.2) 589, (40.9,35.5) 650
Reflected-light panel
42.5 %anisotropic · dual curve
Specimen sRGB 229, 163, 89
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Strong

Crystallography

Crystal system
Monoclinic
Space group
P2/a
Cell parameters
a = 42.6466(16) Å · b = 8.0381(2) Å · c = 34.3957(10) Å
Cell angles
β = 64.684(2) °
Ratio a:b:c
1 : 0.188 : 0.807
Z
4
Type-locality form

Observed only in polished sections.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead10207.2002072.000
36.65%
51SbAntimonyAntimony13121.7601582.880
27.99%
33AsArsenicArsenic1374.922973.986
17.23%
16SSulfurSulfur3032.060961.800
17.01%
29CuCopperCopper163.54663.546
1.12%
Total5654.212100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • As

Synonyms

  • IMA1966-021
  • Launayiet

In other languages

German
IMA 1966-021 · Launayit
Italian
Launayite

Classification

Strunz
10th ed.

2.LB.30

  • 2Sulfides and SulfosaltsClass
  • 2.LUnclassified SulfosaltsDivision
  • 2.LBWith essential PbGroup
  • 2.LB.30LaunayiteSpecies
Dana
8th ed.

03.06.06.01

  • 03SulfosaltsClass
  • 03.062 < ø < 2.49Type
  • 03.06.06— unnamed intermediate level —Group
  • 03.06.06.01LaunayiteSpecies
CIM

5.6.11

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.6Sulpharsenites etc. of Pb aloneGroup
  • 5.6.11LaunayiteSpecies

Literature, links & citation

Citations
  1. 1967Jambor, John Leslie (1967) New lead sulfantimonides from Madoc, Ontario. Part 2 - mineral descriptions. The Canadian Mineralogist, 9 (2) 191-213
  2. 1968Mandarino, J.A.; Kato, A. (1968) New Mineral Names. American Mineralogist, 53 (7-8). 1421-1427
  3. 1981Breskovska, Vesselina V., Mozgova, Nadejda N., Bortnikov, Nicolay S., Gorshkov, Anatoly I., Tzepin, Anatoly I. (1981) New data on chlorine sulfosalts. Bulletin de Minéralogie, 104 (6) 757-762 doi:10.3406/bulmi.1981.7521DOI: 10.3406/bulmi.1981.7521
  4. 2005(2005) Launayite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2008Moëlo, Yves, Makovicky, Emil, Mozgova, Nadejda N., Jambor, John L., Cook, Nigel, Pring, Allan, Paar, Werner, Nickel, Ernest H., Graeser, Stephan, Karup-Møller, Sven, Balic-Žunic, Tonči, Mumme, William G., Vurro, Filippo, Topa, Dan (2008) Sulfosalt systematics: a review. Report of the sulfosalt sub-committee of the IMA Commission on Ore Mineralogy. European Journal of Mineralogy, 20 (1) 7-62 doi:10.1127/0935-1221/2008/0020-1778DOI: 10.1127/0935-1221/2008/0020-1778
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Launayite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/launayite-2341},
  note      = {Accessed 2026-05-11}
}
