Leiteite

ZnAs3+2O4
IMA status
  • Approved
IMA symbol
Lt
Discovered
1977
Also known as
  • IMA1976-026
  • Leiteiet

Where it forms, where it's found

Type locality
Tsumeb Mine (Ongopolo Mine)
  1. Tsumeb
  2. Oshikoto Region
  3. Namibia

-19.2270°, 17.7276°

3recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789101.5 – 2/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colorless to brown
Streak
White
Tenacity
flexible
Cleavage
Perfect

(100)

Flexible and inelastic, somewhat sectile

Density
4.3 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 26° · 2V calc = 38°
Refractive index
1.87 – 1.98
Surface relief
Very high
Principal indices
nα 1.87 · nβ 1.88 · nγ 1.98
Dispersion
relatively strong
UV response
Not fluorescent
Notes

X ∧ a = +11°; Z ∧ c = +10°; Y = b.

Michel-Lévy diagramhighlighted lineδ = 0.1100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1100 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1100 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P1 21/c 1
Cell parameters
a = 4.542(1) Å · b = 5.022(1) Å · c = 17.597(5) Å
Cell angles
β = 90.81(3) °
Ratio a:b:c
1 : 1.106 : 3.874
Z
4
Morphology

No crystal forms

Type-locality form

Cleavable masses to 7 cm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
33AsArsenicArsenic274.922149.844
53.66%
30ZnZincZinc165.38065.380
23.42%
8OOxygenOxygen415.99963.996
22.92%
Total279.220100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1976-026
  • Leiteiet

In other languages

French
leiteite
German
Leiteit
Italian
Leiteite

Classification

Strunz
10th ed.

4.JA.05

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JAArsenites, antimonites, bismuthites; without additional anions, without H2OGroup
  • 4.JA.05LeiteiteSpecies
Dana
8th ed.

45.01.07.01

  • 45Acid and Normal Antimonites and ArsenitesClass
  • 45.01MiscellaneousType
  • 45.01.07— unnamed intermediate level —Group
  • 45.01.07.01LeiteiteSpecies
CIM

23.3

  • 23ArsenitesClass
  • 23.3— unnamed intermediate level —Group
  • 23.3LeiteiteSpecies

Literature, links & citation

Citations
  1. 1906Avery, S. (1906) The constitution of Paris green and its homologues. Journal Of The American Chemical Society, 28 (9). 1155-1164 doi:10.1021/ja01975a005DOI: 10.1021/ja01975a005
  2. 1977Fleischer, Michael, Cabri, Louis J., Pabst, and Adolf (1977) New mineral names. American Mineralogist, 62 (11-12) 1259-1262
  3. 1977Erd, Richard C., Cesbron, Fabien P., Vachey, Helene, Czamanske, Gerald K. (1977) Leiteite: a New Mineral from Tsumeb. The Mineralogical Record, 8 (3) 95-97
  4. 1987Ghose, Subrata, Gupta, P. K Sen, Schlemper, E. O. (1987) Leiteite, ZnAs2O4: A novel type of tetrahedral layer structure with arsenite chains. American Mineralogist, 72 (5-6) 629-632
  5. 2005(2005) Leiteite. Handbook of Mineralogy. Mineralogical Society of America
