Letovicite

(NH4)3H(SO4)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Let
Discovered
1932

Where it forms, where it's found

Geological setting

Burning coal mine waste heaps.

Type locality
Vísky
  1. Blansko District
  2. South Moravian Region
  3. Czech Republic

49.5384°, 16.6256°

20recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101 – 2/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless · white · colourless in transmitted light
Streak
White
Cleavage
Distinct/Good

Distinct, on (001).

Fracture
Irregular/Uneven
Density
1.83 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 75° · 2V calc = 74°
Refractive index
1.501 – 1.525
Surface relief
Moderate
Principal indices
nα 1.501 · nβ 1.516 · nγ 1.525
Dispersion
relatively strong
Extinction
Z = b; X ∧ c = 78°.
Michel-Lévy diagramhighlighted lineδ = 0.0240
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]240 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation240 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Cell parameters
a = 5.87(1) Å · b = 10.17(3) Å · c = 8.27(1) Å
Cell angles
α = 101.1(4) ° · β = 111.1(1) ° · γ = 89.9(2) °
Ratio a:b:c
1 : 1.733 : 1.409
Z
2
Morphology

Tiny pseudo-hexagonal plates on (001). Granular massive.

Twinning

Lamellar, common.

Type-locality form

Corroded tabular crystals.

Comment

Point Group: _1 or 1; Space Group: P_1 or P1.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen815.999127.992
51.77%
16SSulfurSulfur232.06064.120
25.93%
7NNitrogenNitrogen314.00742.021
17.00%
1HHydrogenHydrogen131.00813.104
5.30%
Total247.237100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

In other languages

French
letovicite
German
Letovicit
Italian
Letovicite

Classification

Strunz
10th ed.

7.AD.20

  • 7SulfatesClass
  • 7.ASulfates (selenates, etc.) without additional anions, without H2ODivision
  • 7.ADWith only large cationsGroup
  • 7.AD.20LetoviciteSpecies
Dana
8th ed.

28.01.03.01

  • 28Anhydrous Acid and Normal SulfatesClass
  • 28.01Anhydrous Acid SulfatesType
  • 28.01.03— unnamed intermediate level —Group
  • 28.01.03.01LetoviciteSpecies
CIM

25.1.9

  • 25SulphatesClass
  • 25.1Sulphates of the alkali metals and ammoniumGroup
  • 25.1.9LetoviciteSpecies

Literature, links & citation

Citations
  1. 1857Marignac (1857) Annales des mines: 12: 523 (artificial crystals).
  2. 1880Wyrouboff (1880) Bulletin de la Société française de Minéralogie: 3: 209 (artificial crystals).
  3. 1903Gossner (1903) Zeitschrift für Kristallographie, Mineralogie und Petrographie, Leipzig: 38: 158.
  4. 1908Groth, P. (1908) Chemische Krystallographie Vol. 2. Wilhem Engelmann.
  5. 1932Sekanina, J. (1932) Letovicit, ein neues Mineral und seine Begleiter. Zeitschrift für Kristallographie, 83 (1-6). 117-122 doi:10.1524/zkri.1932.83.1.117DOI: 10.1524/zkri.1932.83.1.117
