Leucosphenite

Na4BaTi2B2Si10O30
IMA status
  • Approved
  • Grandfathered
IMA symbol
Lsp
Discovered
1900
Also known as
  • Leucospheniet
  • Leucosphenit
  • Leucosphenita
  • +1 more

Where it forms, where it's found

Type locality
Narssârssuk pegmatite
  1. Narsaarsuk Plateau
  2. Igaliku
  3. Kujalleq
  4. Greenland

61.0331°, -45.3778°

13recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106 – 6.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colorless · white · pale to dark green · pale yellow · pale gray to blue · brown to black
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

(010), (001)

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
3.04 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 77° · 2V calc = 76°
Refractive index
1.643 – 1.691
Surface relief
High
Principal indices
nα 1.643 – 1.649 · nβ 1.657 – 1.664 · nγ 1.681 – 1.691
Dispersion
weak
Michel-Lévy diagramhighlighted lineδ = 0.0400
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]400 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation400 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 9.814(4) Å · b = 16.851(5) Å · c = 7.210(3) Å
Cell angles
β = 93.35(3) °
Ratio a:b:c
1 : 1.717 : 0.735
Z
2
Morphology

Often wedge shaped. As rosettes and laminated masses. Type material forms include: a(100), b(010), c(001), x(011), d(101), m(110), n(130), s(112), p(111), g(133), r(263).

Twinning

Common, perpendicular to (001), contact plane (001).

Type-locality form

Fairly well developed crystals to 2x5 mm in size, though most much smaller.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3015.999479.970
43.34%
14SiSiliconSilicon1028.085280.850
25.36%
56BaBariumBarium1137.327137.327
12.40%
22TiTitaniumTitanium247.86795.734
8.65%
11NaSodiumSodium422.99091.960
8.30%
5BBoronBoron210.81021.620
1.95%
Total1107.461100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Nb
  • Mn
  • Mg
  • Ca
  • Sr
  • K

Synonyms

  • Leucospheniet
  • Leucosphenit
  • Leucosphenita
  • Unnamed (MSH UK-8)

In other languages

German
Leukosphenit
Italian
Leucosfenite · Leucosphenite

Classification

Strunz
10th ed.

9.DP.15

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DPTransitional ino-phyllosilicate structuresGroup
  • 9.DP.15LeucospheniteSpecies
Dana
8th ed.

72.05.02.01

  • 72Phyllosilicates Two-dimensional Infinite Sheets with Other Than Six-membered RingsClass
  • 72.05Two-Dimensional Infinite Sheets with Other Than Six-Membered Rings with corrugated and complex layersType
  • 72.05.02Leucospenite and related speciesGroup
  • 72.05.02.01LeucospheniteSpecies
CIM

17.5.33

  • 17Silicates Containing other AnionsClass
  • 17.5BorosilicatesGroup
  • 17.5.33LeucospheniteSpecies

Literature, links & citation

Citations
  1. 1898Flink, Gust. (1898) Berättelse om en Mineralogsik Resa i Syd-Grönland sommaren 1897. [Narrative of a Mineralogical Journey in South Greenland in the summer of 1897]. Meddelelser om Grønland, 14. 221-262 doi:10.7146/mog.v14.139846DOI: 10.7146/mog.v14.139846
  2. 1901Flink, G. (1901) Part I: On the Minerals from Narsarsuk on the Firth of Tunugdliarfik in Southern Greenland. Meddelelser om Grønland, 24. 7-180
  3. 1955Milton, C., Axelrod, J.M., Grimaldi, F.S. (1955) New minerals, reedmergnerite (Na2O·B2O3·6SiO2) and eitelite (Na2O·MgO·2CO2) associated with leucosphenite, shortite, searlesite, and crocidolite in the Green River formation, Utah. American Mineralogist: 40: 326-327.
  4. 1971Shumyatskaya, N.G., Voronkov, A.A., Belov, N.V. (1971) X-ray diffraction study of leucosphenite. Soviet Physics - Crystallography: 16: 416-422.
  5. 1972Pabst, A., Milton, Charles (1972) Leucosphenite, and its occurrence in the Green River formation of Utah and Wyoming. American Mineralogist, 57 (11-12) 1801-1822
