Liberite

Li2Be(SiO4)
IMA status
  • Approved
IMA symbol
Lbr
Discovered
1964

Where it forms, where it's found

Geological setting

In veins cutting lepidolite-fluorite-magnetite "ribbon rock" in tactite

Type locality
Xianghualing Mine
  1. Xianghualing Sn-polymetallic ore field
  2. Linwu Co.
  3. Chenzhou
  4. Hunan
  5. China

25.4586°, 112.5672°

2recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789107/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Pale yellow to brown
Tenacity
brittle
Cleavage
Distinct/Good

Perfect on (010), distinct on (100) and (001)

Density
2.6875 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 66° · 2V calc = 66 – 66.3°
Refractive index
1.622 – 1.638
Surface relief
Moderate
Principal indices
nα 1.622 · nβ 1.6332 · nγ 1.638
Dispersion
r > v to r < v strong
Notes

Z^c(a in structure cell)=41 degrees

Michel-Lévy diagramhighlighted lineδ = 0.0160
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]160 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation160 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#6
Cell parameters
a = 4.68 Å · b = 4.95 Å · c = 6.13 Å
Cell angles
β = 90.5 °
Ratio a:b:c
1 : 1.058 : 1.310
Z
2
Morphology

Minute aggregates occasionally display pinnacoidal faces.

Comment

Pseudo-orthorhombic.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen415.99963.996
55.66%
14SiSiliconSilicon128.08528.085
24.43%
3LiLithiumLithium26.94013.880
12.07%
4BeBerylliumBeryllium19.0129.012
7.84%
Total114.973100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Mg
  • Ca
  • Na
  • K
  • H2O

In other languages

German
Liberit
Spanish
Liberita
Italian
Liberite

Classification

Strunz
10th ed.

9.AA.10

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AANesosilicates without additional anions; cations in tetrahedral [4] coordinationGroup
  • 9.AA.10LiberiteSpecies
Dana
8th ed.

51.01.02.01

  • 51Nesosilicates Insular Sio4 Groups OnlyClass
  • 51.01Insular SiO4 Groups Only with cations in [4] coordinationType
  • 51.01.02— unnamed intermediate level —Group
  • 51.01.02.01LiberiteSpecies
CIM

14.3.4

  • 14Silicates not Containing AluminumClass
  • 14.3Silicates of BeGroup
  • 14.3.4LiberiteSpecies

Literature, links & citation

Citations
  1. 1964Chao Ch'un-lin (1964): Liberite Li2BeSiO4, a new lithium-beryllium silicate mineral from the Nanling Ranges, South China. Acta Geologica Sinica 44(3), 334-342 (in Chinese with English abstract). - American Mineralogist (1965), 50, 519 (abstract).
  2. 1966Han-ching, C. (1966): The crystal structure of liberite. Kexue Tongbao 17, 425-428.
  3. 1975West, Anthony R. (1975) Crystal chemistry of liberite, Li2Be SiO4 and Li2Be Ge O4. Bulletin de Minéralogie, 98 (1) 6-10 doi:10.3406/bulmi.1975.6951DOI: 10.3406/bulmi.1975.6951
  4. 2001(2001) Liberite. Handbook of Mineralogy. Mineralogical Society of America
