Likasite

Cu3(NO3)(OH)5 · 2H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Lik
Discovered
1955
Also known as
  • Likasiet

Where it forms, where it's found

Geological setting

A rare secondary mineral in copper deposits.

Type locality
Likasi Mine
  1. Likasi
  2. Kambove Territory
  3. Haut-Katanga
  4. DR Congo

-11.0042°, 26.7428°

12recorded occurrences
Source · OpenStreetMap

Physical

Transparency
Transparent
Colour
Sky Blue
Cleavage
Perfect

on (001)

Density
2.96 g/cm³

Optical

Optical type
Biaxial
Refractive index
1.61 – 1.69
Surface relief
High
Principal indices
nα 1.61 – 1.615 · nγ 1.685 – 1.69
Pleochroism
Visible

X = Pale greenish blue Y = Purplish blue

Dispersion
relatively strong
Notes

X = a; Z = b.

Michel-Lévy diagramhighlighted lineδ = 0.0750
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]750 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation750 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 5.830(1) Å · b = 6.775(1) Å · c = 21.711(5) Å
Ratio a:b:c
1 : 1.162 : 3.724
Z
4
Morphology

Crystals to 1.5mm, rectangular section, tabular on (001). Additional forms include (010), (100), (101), (012), (014), (018).

Type-locality form

Crystals implanted on cuprite or as blue masses in cuprite.

Comment

Space Group: P cmn

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
29CuCopperCopper363.546190.638
51.01%
8OOxygenOxygen1015.999159.990
42.81%
7NNitrogenNitrogen114.00714.007
3.75%
1HHydrogenHydrogen91.0089.072
2.43%
Total373.707100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Likasiet

In other languages

German
Likasit
Italian
Likasite

Classification

Strunz
10th ed.

5.ND.05

  • 5CarbonatesClass
  • 5.NNITRATESDivision
  • 5.NDWith OH (etc.) and H2OGroup
  • 5.ND.05LikasiteSpecies
Dana
8th ed.

19.01.05.01

  • 19Nitrates Containing Hydroxyl or HalogenClass
  • 19.01Anhydrous Nitrates Containing Hydroxyl or HalogenType
  • 19.01.05— unnamed intermediate level —Group
  • 19.01.05.01LikasiteSpecies

Literature, links & citation

Citations
  1. 1955Schoep, Alfred; Borchert, W.; Kohler, K. (1955) La likasite Cu12(OH)14(NO3)4(PO4)2, nouveau minéral. Bulletin de la Société française de Minéralogie et de Cristallographie, 78 (1). 84-88 doi:10.3406/bulmi.1955.4988DOI: 10.3406/bulmi.1955.4988
  2. 1955Fleischer, M. (1955) New mineral names. American Mineralogist, 40 (9-10). 941-944
  3. 1973Deliens, Michel (1973) La likasite de Likasi (République du Zaïre). Bulletin de la Société française de Minéralogie et de Cristallographie, 96 (2). 143-145 doi:10.3406/bulmi.1973.6796DOI: 10.3406/bulmi.1973.6796
  4. 1977Declercq, J. P., Germain, G., Piret, P. (1977) Composition et structure de la likasite, Cu3P2H3(NO3) (OH)2.H2O. Acta Crystallographica Section B Structural Crystallography and Crystal Chemistry, 33 (5) 1422-1427 doi:10.1107/s0567740877006219DOI: 10.1107/s0567740877006219
  5. 1978Fleischer, Michael, Cabri, Louis J. (1978) New mineral names. American Mineralogist, 63 (5-6) 598-600
