Lindströmite

Pb3Cu3Bi7S15
IMA status
  • Approved
  • Grandfathered
IMA symbol
Lsm
IMA approved
1975
Also known as
  • IMA1975-005a
  • Lindstroemite
  • Lindströmiet

Where it forms, where it's found

Type locality
Gladhammar mines
  1. Västervik
  2. Kalmar County
  3. Sweden

57.7194°, 16.4250°

46recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103 – 3.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Lead-grey
Streak
Black
Cleavage
Distinct/Good
Fracture
Irregular/Uneven · Conchoidal
Density
7.01 g/cm³

Optical

Tropism
Anisotropic
Reflectance R%
(42.3,46.0) 400, (42.2,45.8) 420, (42.1,45.6) 440, (42.0,45.4) 460, (41.8,45.3) 480, (41.6,45.2) 500, (41.4,45.3) 520, (41.1,45.4) 540, (41.0,45.5) 560, (40.7,45.3) 580, (40.3,45.1) 600, (40.1,45.0) 620, (39.8,44.7) 640, (39.6,44.4) 660, (39.3,44.0) 680, (39.0,43.6) 700
Reflected-light panel
40.9 %anisotropic · dual curve
Specimen sRGB 225, 159, 90
White reference100 % reflector under same lamp
R₁ R₂
Mode

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 56.08 Å · b = 11.56 Å · c = 4.00 Å
Ratio a:b:c
1 : 0.206 : 0.071
Z
4
Morphology

Prismatic [001], lacking terminal faces; striated [001]. Forms include (100), (010), (110), (510), (410), (310), (520), (210), (530), (230), (120), (130), (140).

Type-locality form

Prismatic crystals to 1 cm in length and several mm thick, on quartz.

Comment

SG Pbnm; cell parameters are slightly variable

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth7208.9801462.860
53.08%
82PbLeadLead3207.200621.600
22.55%
16SSulfurSulfur1532.060480.900
17.45%
29CuCopperCopper363.546190.638
6.92%
Total2755.998100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1975-005a
  • Lindstroemite
  • Lindströmiet

In other languages

German
IMA 1975-005a · Lindströmit
Italian
Lindströmite

Classification

Strunz
10th ed.

2.HB.05a

  • 2Sulfides and SulfosaltsClass
  • 2.HSulfosalts of SnS archetypeDivision
  • 2.HBWith Cu, Ag, Fe, Sn and PbGroup
  • 2.HB.05aLindströmiteSpecies
Dana
8th ed.

03.04.05.07

  • 03SulfosaltsClass
  • 03.04ø = 3Type
  • 03.04.05Aikinite Group (Orthorhombic containing Pb, Cu, Bi, & S)Group
  • 03.04.05.07LindströmiteSpecies
CIM

5.7.5

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.7Sulpharsenites etc. of Pb and other metalsGroup
  • 5.7.5LindströmiteSpecies

Literature, links & citation

Citations
  1. 1924Johansson, K. (1924) Bidrag till Gladhammar-gruvornas mineralogi [Contribution to the mineralogy of the Gladhammar mines]. Arkiv für Kemi, Mineralogi och Geologi [Archive for Chemistry, Mineralogy and Geology], 9 (8) 1-22
  2. 1925Foshag, W.F. (1925) New minerals: new species. American Mineralogist: 10: 157-158.
  3. 1944Palache, Charles, Berman, Harry, Frondel, Clifford (1944) The System of Mineralogy (7th ed.) Vol. 1 - Elements, Sulfides, Sulfosalts, Oxides. John Wiley and Sons, New York.
  4. 1966Welin, Eric (1966) Notes on the mineralogy of Sweden. 5. Bismuth-bearing sulphosalts from Gladhammar, a revision. Arkiv för Mineralogi och Geologi, 4 (4, nr 13). 377-386
  5. 1976Mumme, William G., Welin, Eric, Weunsch, B. J. (1976) Crystal chemistry and proposed nomenclature for sulfosalts intermediate in the system bismuthinite-aikinite (Bi2S3-CuPbBiS3). American Mineralogist, 61 (1-2). 15-20
