Luddenite

Cu2Pb2Si5O14 · 14H2O
IMA status
  • Approved
IMA symbol
Ldd
Discovered
1982
Also known as
  • IMA1981-032
  • Luddeniet

Where it forms, where it's found

Geological setting

Oxidized Cu-Zn ores.

Type locality
Unnamed Base Metals prospect [3]
  1. Artillery Peak
  2. Artillery Mountains
  3. Mohave County
  4. Arizona
  5. USA
3recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Translucent nickel green
Streak
Pale nickel green
Cleavage
Distinct/Good

The plane of flattening is a cleavage plane.

Density
4.45 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 40°
Refractive index
1.852 – 1.867
Surface relief
Very high
Principal indices
nα 1.852 · nγ 1.867
Pleochroism
Visible

gamma=rich emerald green, alpha = beta = yellow green.

Dispersion
none
Michel-Lévy diagramhighlighted lineδ = 0.0150
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]150 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation150 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 7.85 Å · b = 20.06 Å · c = 14.72 Å
Cell angles
β = 90.78 °
Ratio a:b:c
1 : 2.555 : 1.875
Z
4
Morphology

Grains not exceeding 0.01 mm in size. They form in rosettes or fan-shaped aggregates closely packed together. Where individual grains can be discerned, they are scales or plates with wedge-shaped terminations.

Twinning

Twinned on a plane normal to the cleavage.

Type-locality form

Microcrystalline, individual grains not exceeding 0.01 mm in size.

Comment

Point Group: n.d.; Space Group: n.d.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2815.999447.972
38.68%
82PbLeadLead2207.200414.400
35.78%
14SiSiliconSilicon528.085140.425
12.13%
29CuCopperCopper263.546127.092
10.97%
1HHydrogenHydrogen281.00828.224
2.44%
Total1158.113100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti

Synonyms

  • IMA1981-032
  • Luddeniet

In other languages

German
IMA 1981-032 · Luddenit
Italian
Luddenite

Classification

Strunz
10th ed.

9.HH.10

  • 9SilicatesClass
  • 9.HUnclassified silicatesDivision
  • 9.HHWith PbGroup
  • 9.HH.10LuddeniteSpecies
Dana
8th ed.

78.07.11.01

  • 78Unclassified SilicatesClass
  • 78.07Unclassified silicates wholly unclassified silicatesType
  • 78.07.11— unnamed intermediate level —Group
  • 78.07.11.01LuddeniteSpecies
CIM

14.13.3

  • 14Silicates not Containing AluminumClass
  • 14.13Silicates of PbGroup
  • 14.13.3LuddeniteSpecies

Literature, links & citation

Citations
  1. 1982Williams, S. A. (1982) Luddenite, a new copper-lead silicate from Arizona. Mineralogical Magazine, 46 (340) 363-364 doi:10.1180/minmag.1982.046.340.11 DOI: 10.1180/minmag.1982.046.340.11
  2. 1983Dunn, Pete J., Fleischer, Michael (1983) New mineral names. American Mineralogist, 68 (5-6) 642-645
  3. 2001(2001) Luddenite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2015Frost, Ray L., López, Andrés, Xi, Yunfei, Scholz, Ricardo (2015) A vibrational spectroscopic study of the copper bearing silicate mineral luddenite. Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy, 137. 717-720 doi:10.1016/j.saa.2014.08.026DOI: 10.1016/j.saa.2014.08.026
