Luetheite

CuAl(AsO4)(OH)2
IMA status
  • Approved
IMA symbol
Lut
Discovered
1976
IMA approved
1976
Also known as
  • IMA1976-011
  • Luetheiet
  • Luethit
  • +2 more

Where it forms, where it's found

Geological setting

Intensely altered volcanic rocks.

Type locality
Humboldt Mine area
  1. Harshaw Mining District
  2. Patagonia Mountains
  3. Santa Cruz County
  4. Arizona
  5. USA
6recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Blue · pale green (upon alteration).

May be tan

Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

On (100), fair to good.

Thin cleavage foliae tend to bend before breaking.

Density
4.28 g/cm³

Optical

Optical type
Biaxial (+) · 2V calc = 88°
Refractive index
1.752 – 1.796
Surface relief
High
Principal indices
nα 1.752 · nβ 1.775 · nγ 1.796
Pleochroism
Weak

Faint in pale blues.

Dispersion
r < v marked
Extinction
X = b; Z ∧ c ≃ 10°.
UV response
Not fluorescent.
Notes

Absorption: Y = Z > X.

Michel-Lévy diagramhighlighted lineδ = 0.0440
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]440 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation440 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#15
Cell parameters
a = 14.743 Å · b = 5.093 Å · c = 5.598 Å
Cell angles
β = 101.49 °
Ratio a:b:c
1 : 0.345 : 0.380
Z
2
Morphology

Crystals thin blades exhibiting prominent (100) with (140) and (011). Commonly in spherulitic aggregates.

Twinning

Observed at a very fine scale.

Type-locality form

Cavity fillings. Spherules of randomly arranged plates. The plates are well-formed crystals up to 0.2 mm in largest dimension.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen615.99995.994
36.44%
33AsArsenicArsenic174.92274.922
28.44%
29CuCopperCopper163.54663.546
24.12%
13AlAluminiumAluminium126.98226.982
10.24%
1HHydrogenHydrogen21.0082.016
0.76%
Total263.460100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1976-011
  • Luetheiet
  • Luethit
  • Luethita
  • Luethite

In other languages

German
IMA 1976-011 · Luetheit
Italian
Luetheite

Classification

Strunz
10th ed.

8.DD.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DDWith only medium-sized cations, (OH, etc.):RO4= 2:1Group
  • 8.DD.05LuetheiteSpecies
Dana
8th ed.

42.07.10.02

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.07(AB)2(XO4)Zq·xH2OType
  • 42.07.10Chenevixite GroupGroup
  • 42.07.10.02LuetheiteSpecies
CIM

20.4.4

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.4Arsenates of Group III metals (Al, rare earths)Group
  • 20.4.4LuetheiteSpecies

Literature, links & citation

Citations
  1. 1977Fleischer, Michael, Pabst, Adolf, Mandarino, J. A., Chao, George Y. (1977) New mineral names. American Mineralogist, 62 (9-10) 1057-1061
  2. 1977Williams, S. A. (1977) Luetheite, Cu2Al2(AsO4)2(OH)H2O, a new mineral from Arizona, compared with chenevixite. Mineralogical Magazine, 41 (317) 27-32 doi:10.1180/minmag.1977.041.317.04 DOI: 10.1180/minmag.1977.041.317.04
  3. 2000Burns, P. C., Smith, J. V., Steele, I. M. (2000) Arizona porphyry copper/hydrothermal deposits I. The structure of chenevixite and luetheite. Mineralogical Magazine, 64 (1). 25-30 doi:10.1180/002646100549102DOI: 10.1180/002646100549102
  4. 2005(2005) Luetheite. Handbook of Mineralogy. Mineralogical Society of America
