Macfallite

Ca2Mn3+3(SiO4)(Si2O7)(OH)3
IMA status
  • Approved
IMA symbol
Mcf
Discovered
1974
IMA approved
1974
Also known as
  • IMA1974-057
  • Macfalliet

Where it forms, where it's found

Type locality
Manganese Mine
  1. Copper Harbor
  2. Grant Township
  3. Keweenaw County
  4. Michigan
  5. USA

47.4549°, -87.8650°

7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Silky · Sub-adamantine
Transparency
Transparent · Translucent
Colour
Reddish-brown · maroon · dull pink
Streak
Brown with a reddish tint
Cleavage
Perfect

(001)

Density
3.43 g/cm³

Optical

Optical type
Biaxial (+/-) · 2V measured = 86° · 2V calc = 78 – 88°
Refractive index
1.773 – 1.815
Surface relief
High
Principal indices
nα 1.773 – 1.775 · nβ 1.795 · nγ 1.810 – 1.815
Pleochroism
Visible

X = colorless to yellow; Y = light brown; Z = dark brown to reddish brown.

Dispersion
r < v medium
Notes

2V(meas.) = Very large

Michel-Lévy diagramhighlighted lineδ = 0.0385
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]385 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation385 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/m
Cell parameters
a = 10.235(3) Å · b = 6.086(6) Å · c = 8.970(5) Å
Cell angles
β = 110.75(3) °
Ratio a:b:c
1 : 0.595 : 0.876
Z
2
Twinning

By reflection on (100), commonly repeated.

Type-locality form

radial and framboidal aggregates

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
40.27%
25MnManganeseManganese354.938164.814
29.63%
14SiSiliconSilicon328.08584.255
15.15%
20CaCalciumCalcium240.07880.156
14.41%
1HHydrogenHydrogen31.0083.024
0.54%
Total556.235100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Al
  • Fe
  • Cr
  • V
  • Cu
  • Mg
  • K
  • Na
  • H2O

Synonyms

  • IMA1974-057
  • Macfalliet

In other languages

French
Macfallite
German
IMA 1974-057 · Macfallit
Italian
Macfallite

Classification

Strunz
10th ed.

9.BG.15

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BGSorosilicates with mixed SiO4 and Si2O7 groups; cations in octahedral [6] and greater coordinationGroup
  • 9.BG.15MacfalliteSpecies
Dana
8th ed.

58.02.03.02

  • 58Sorosilicates Insular, Mixed, Single, and Larger Tetrahedral GroupsClass
  • 58.02Insular, Mixed, Single, and Larger Tetrahedral Groups with cations in [6] and higher coordination; single and double groups (n = 1, 2)Type
  • 58.02.03Sursassite and related speciesGroup
  • 58.02.03.02MacfalliteSpecies
CIM

16.16.20

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.16Aluminosilicates of MnGroup
  • 16.16.20MacfalliteSpecies

Literature, links & citation

Citations
  1. 1979Moore, Paul B., Ito, Jun, Steele, Ian M. (1979) MacFallite and orientite: calcium manganese (III) silicates from upper Michigan. Mineralogical Magazine, 43 (327) 325-331 doi:10.1180/minmag.1979.043.327.02 DOI: 10.1180/minmag.1979.043.327.02
  2. 1980Fleischer, Michael, Cabri, Louis J., Pabst, Adolf (1980) New Mineral Names. American Mineralogist, 65 (3-4) 406-408
  3. 1980Wilson, Wendell E. (1980) Abstracts of New Mineral Descriptions. The Mineralogical Record, 11 (2) 111-112
  4. 1985Moore, Paul B., Shen, Jinchuan, Araki, Takaharu (1985) Crystal chemistry of the 2∞[M3+2φ2(TO4)2] sheet: structural principles and crystal structures of ruizite, macfallite and orientite. American Mineralogist, 70 (1-2) 171-181
  5. 1989Neues Jahrbuch für Mineralogie, Monatshefte (1989): 455.
