Magadiite

Na2Si14O28(OH)2 · 8H2O
IMA status
  • Approved
IMA symbol
Mgd
Discovered
1967
Also known as
  • IMA1967-017
  • Magadiiet

Where it forms, where it's found

Geological setting

Evaporite from saline brine.

Type locality
Lake Magadi
  1. Kajiado County
  2. Kenya

-1.9091°, 36.2719°

12recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent · Opaque
Colour
White
Streak
White
Cleavage

Tenacity: Puttylike

Density
2.25 g/cm³

Optical

Optical type
Biaxial
Refractive index
1.47
Surface relief
Low
Principal indices
nα 1.47
Dispersion
relatively weak

Crystallography

Crystal system
Orthorhombic
Space group
#23
Cell parameters
a = 10.5035(9) Å · b = 10.0262(9) Å · c = 61.9608(46) Å
Ratio a:b:c
1 : 0.955 : 5.899
Morphology

Putty-like laminae to very thin platy.

Type-locality form

White putty-like laminae, in beds varying in thickness from 5 cm to 60 cm.

Comment

Space Group: F2dd; Z undetermined

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3815.999607.962
57.07%
14SiSiliconSilicon1428.085393.190
36.91%
11NaSodiumSodium222.99045.980
4.32%
1HHydrogenHydrogen181.00818.144
1.70%
Total1065.276100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Al
  • Fe
  • Mn
  • Mg
  • Ca
  • K

Synonyms

  • IMA1967-017
  • Magadiiet

In other languages

German
IMA 1967-017 · Magadiit
Italian
Magadiite

Classification

Strunz
10th ed.

9.EA.20

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EASingle nets of tetrahedra with 4-, 5-, (6-), and 8-membered ringsGroup
  • 9.EA.20MagadiiteSpecies
Dana
8th ed.

78.07.12.01

  • 78Unclassified SilicatesClass
  • 78.07Unclassified silicates wholly unclassified silicatesType
  • 78.07.12— unnamed intermediate level —Group
  • 78.07.12.01MagadiiteSpecies
CIM

14.1.5

  • 14Silicates not Containing AluminumClass
  • 14.1Silicates of the alkali metalsGroup
  • 14.1.5MagadiiteSpecies

Literature, links & citation

Citations
  1. 1967Eugster, H. P. (1967) Hydrous Sodium Silicates from Lake Magadi, Kenya: Precursors of Bedded Chert. Science, 157 (3793). 1177-1180 doi:10.1126/science.157.3793.1177DOI: 10.1126/science.157.3793.1177
  2. 1968McAtee, J. L., House, R., Eugster, H. P. (1968) Magadiite from Trinity County, California. American Mineralogist, 53 (11-12) 2061-2069
  3. 1969Bricker, Owen P. (1969) Stability constants and Gibbs free energies of formation of magadiite and kenyaite. American Mineralogist, 54 (7-8) 1026-1033
  4. 1969Brindley, G. W. (1969) Unit cell of magadiite in air, in vacuo and under other conditions. American Mineralogist, 54 (11-12) 1583-1591
  5. 1969Rooney, Thomas P, Jones, Blair, F., Neal, James T. (1969) Magadiite from Alkali Lake, Oregon. American Mineralogist, 54 (7-8) 1034-1043
