Magnesiostaurolite

Mg(Mg,Li)3(Al,Mg)18Si8O44(OH)4
IMA status
  • Approved
IMA symbol
Mst
IMA approved
1992
Also known as
  • IMA1992-035
  • Magnesiostauroliet
  • Magnesiostaurolit

Where it forms, where it's found

Geological setting

Occurs together with talc, clinochlore and kyanite (or alone, armouring corundum) as inclusions in pyrope megablasts from the ultra-high-pressure metamorphic terrane of the Dora-Maira massif, Italian Western Alps.

Type locality
Gilba Valley
  1. Brossasco
  2. Cuneo Province
  3. Piedmont
  4. Italy

44.6000°, 7.2831°

6recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789107 – 7.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colorless · light cloudy gray · tan
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

(010)

Fracture
Irregular/Uneven
Density
3.54 g/cm³

Optical

Optical type
· 2V measured = 90°
Birefringence
Low (< 0.010) with a mean value of n = 1.709(2) at 592 nm.
Pleochroism
Non-pleochroic
UV response
Creamy-yellow in shortwave, somewhat dull orange in longwave 350 nm.
Michel-Lévy diagramhighlighted lineδ = 0.0100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]100 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation100 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 7.871 Å · b = 16.541 Å · c = 5.632 Å
Ratio a:b:c
1 : 2.102 : 0.716
Unit cell volume
733.3 ų
Z
1
Morphology

Stout blades, rarely elongated.

Twinning

Sometimes tweed texture.

Type-locality form

Rare anhedral isolated grains with size ranging from a few tens to 250 μm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen4815.999767.952
37.68%
12MgMagnesiumMagnesium2224.305534.710
26.24%
13AlAluminiumAluminium1826.982485.676
23.83%
14SiSiliconSilicon828.085224.680
11.03%
3LiLithiumLithium36.94020.820
1.02%
1HHydrogenHydrogen41.0084.032
0.20%
Total2037.870100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1992-035
  • Magnesiostauroliet
  • Magnesiostaurolit

In other languages

German
IMA 1992-035 · Magnesiostaurolith
Italian
magnesiostaurolite

Classification

Strunz
10th ed.

9.AF.30

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AFNesosilicates with additional anions; cations in [4], [5] and/or only [6] coordinationGroup
  • 9.AF.30MagnesiostauroliteSpecies

Group, growth & confusion

In the same group
2 members
Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. Terra Nova, Abstract supplement 1, 9, 40
  2. 1988Enami, Masaki, Zang, Qijia (1988) Magnesian staurolite in garnet-corundum rocks and eclogite from the Donghai district, Jiangsu province, east China. American Mineralogist, 73 (1-2) 48-56
  3. 1995Peacock, S.M., Goodge, J.W. (1995) Eclogite-facies metamorphism preserved in tectonic blocks from a lower crustal shear zone, central Transantarctic Mountains, Antarctica. Lithos, 36 (1) 1-13 doi:10.1016/0024-4937(95)00006-2DOI: 10.1016/0024-4937(95)00006-2
  4. 1995Fockenberg, Thomas (1995) Synthesis and chemical variability of Mg-staurolite in the system MgO-Al2O3-SiO2-H2O as a function of water pressure. European Journal of Mineralogy, 7 (6) 1373-1380 doi:10.1127/ejm/7/6/1373DOI: 10.1127/ejm/7/6/1373
  5. 1998Fockenberg, Thomas (1998) An experimental investigation on the P-T stability of Mg-staurolite in the system MgO-Al2O3-SiO2-H2O. Contributions to Mineralogy and Petrology, 130 (2). 187-198 doi:10.1007/s004100050359DOI: 10.1007/s004100050359
