Magnesiotaaffeite-6N’3S

Mg2BeAl6O12
IMA status
  • Approved
IMA symbol
Mtf- 6N'3S
Discovered
1967
Also known as
  • Magnesiotaaffeiet-6N’3S
  • Magnesiotaaffeit-6N’3S
  • Magnesiotaaffeite-6N3S
  • +3 more

Where it forms, where it's found

Type locality
Ernabella Mission
  1. Aṉangu Pitjantjatjara Yankunytjatjara (APY
  2. APY Lands)
  3. South Australia
  4. Australia

-26.2500°, 132.1667°

7recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789108 – 8.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colorles to pale shades of olive-green
Streak
colorless
Tenacity
brittle
Cleavage
Perfect

(0001)

Optical

Optical type
Uniaxial (-)
Refractive index
1.735 – 1.739
Surface relief
High
Principal indices
nω 1.739 · nε 1.735
Birefringence
0.004
Pleochroism
Non-pleochroic
UV response
Unknown if any has been tested in UV
Michel-Lévy diagramhighlighted lineδ = 0.0040
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]40 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation40 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#99
Cell parameters
a = 5.67 Å · c = 41.09 Å
Z
6
Type-locality form

Light colored vitreous translucent mineral

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1215.999191.988
46.66%
13AlAluminiumAluminium626.982161.892
39.34%
12MgMagnesiumMagnesium224.30548.610
11.81%
4BeBerylliumBeryllium19.0129.012
2.19%
Total411.502100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Magnesiotaaffeiet-6N’3S
  • Magnesiotaaffeit-6N’3S
  • Magnesiotaaffeite-6N3S
  • Musgravit
  • Musgravita
  • Musgravite

Classification

Strunz
10th ed.

4.FC.25

  • 4OxidesClass
  • 4.FHydroxides (without V or U)Division
  • 4.FCHydroxides with OH, without H2O; corner-sharing octahedraGroup
  • 4.FC.25Magnesiotaaffeite-6N’3SSpecies
Dana
8th ed.

07.02.12.01

  • 07Multiple OxidesClass
  • 07.02AB2X4Type
  • 07.02.12Taaffeite Group (T2 = Be + T)Group
  • 07.02.12.01Magnesiotaaffeite-6N’3SSpecies
CIM

7.4.6

  • 7Oxides and HydroxidesClass
  • 7.4Oxides of Be, Mg and the alkaline earthsGroup
  • 7.4.6Magnesiotaaffeite-6N’3SSpecies

Group, growth & confusion

In the same group
1 members

Literature, links & citation

Citations
  1. 1983Nuber, B., Schmetzer, K. (1983) Crystal structures of ternary Be-Mg-Al oxides: taaffeite, BeMg3Al8O16, and musgravite, BeMg2Al6O12. Neues Jahrbuch für Mineralogie, Monatshefte: 1983: 393-402.
  2. 1983Schmetzer, K. (1983) Crystal chemistry of natural Be-Mg-Al-oxides: taaffeite, taprobanite, musgravite. Neues Jahrbuch für Mineralogie - Abhandlungen, 146 (1). 15-28 doi:10.1127/njma/146/1983/15DOI: 10.1127/njma/146/1983/15
  3. 1998Kiefert, Lore, Schmetzer, Karl (1998) Distinction of taaffeite and musgravite. The Journal of Gemmology, 26 (3) 165-167 doi:10.15506/jog.1998.26.3.165DOI: 10.15506/jog.1998.26.3.165
  4. 2002Armbruster, Thomas (2002) Revised nomenclature of högbomite, nigerite, and taaffeite minerals. European Journal of Mineralogy, 14 (2) 389-395 doi:10.1127/0935-1221/2002/0014-0389DOI: 10.1127/0935-1221/2002/0014-0389
  5. 2005Schmetzer, Karl, Kiefert, Lore, Bernhardt, Heinz-Jürgen, Burford, Murray (2005) Gem-quality musgravite from Sri Lanka. The Journal of Gemmology, 29 (5) 281-289 doi:10.15506/jog.2005.29.5.281DOI: 10.15506/jog.2005.29.5.281
