Mawsonite

Cu6Fe2SnS8
IMA status
  • Approved
IMA symbol
Maw
Discovered
1965
Also known as
  • IMA1964-030
  • Mawsoniet

Where it forms, where it's found

Geological setting

Massive to disseminated copper ores

Type locality
Royal George Mine
  1. Tingha
  2. Hardinge Co.
  3. New South Wales
  4. Australia

-29.9470°, 151.2299°

108recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Brownish orange
Cleavage
Imperfect/Fair

2 imperfect at right angles.

Density
4.65 g/cm³

Optical

Pleochroism
Strong

Orange Brown with slight orange tint

Optical colour
Brownish orange
Anisotropism
Very strong - Bright straw yellow to royal blue
Tropism
Anisotropic
Reflectance R%
(15.0,19.0) 400, (17.1,21.0) 440, (20.3,23.1) 480, (25.0,25.3) 520, (31.2,27.4) 560, (36.4,29.6) 600, (39.9,32.0) 640, (41.4,33.8) 680, (41.6,34.4) 700
Reflected-light panel
29.8 %anisotropic · dual curve
Specimen sRGB 223, 134, 47
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Very strong - Bright straw yellow to royal blue
Reflected colour
Brownish orange

Crystallography

Crystal system
Tetragonal
Space group
#151
Cell parameters
a = 7.603(2) Å · c = 5.358(1) Å
Z
1
Morphology

Rounded to irregular inclusions in bornite.

Type-locality form

Rounded to irregular inclusions in bornite (from which it was exsolved).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
29CuCopperCopper663.546381.276
43.92%
16SSulfurSulfur832.060256.480
29.54%
50SnTinTin1118.710118.710
13.67%
26FeIronIron255.845111.690
12.87%
Total868.156100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Zn
  • Se

Synonyms

  • IMA1964-030
  • Mawsoniet

In other languages

German
IMA 1964-030 · Mawsonit
Italian
Mawsonite
Japanese
モースン鉱

Classification

Strunz
10th ed.

2.CB.20

  • 2Sulfides and SulfosaltsClass
  • 2.CMetal Sulfides, M: S = 1: 1 (and similar)Division
  • 2.CBWith Zn, Fe, Cu, Ag, etc.Group
  • 2.CB.20MawsoniteSpecies
Dana
8th ed.

02.09.03.01

  • 02SulfidesClass
  • 02.09AmBnXp, with (m+n):p = 1:1Type
  • 02.09.03Mawsonite GroupGroup
  • 02.09.03.01MawsoniteSpecies
CIM

6.1.8

  • 6Sulphosalts - Sulphostannates, Sulphogermanates,Sulpharsenates, Sulphantimonates, Sulphovanadates and SulphohalidesClass
  • 6.1Sulphostannates and other sulfides containing SnGroup
  • 6.1.8MawsoniteSpecies

Literature, links & citation

Citations
  1. 1965Markham, N. L., Lawrence, L. J. (1965) Mawsonite, a new copper-iron-tin sulfide from Mt. Lyell, Tasmania and Tingha, New South Wales. American Mineralogist, 50 (7-8) 900-908
  2. 1967Lévy, C. (1967) Contribution a la minéralogie des sulfures de cuivre du type Cu3XS4. Mémoires du Bureau de Recherches Géologiques et Minières: 54: 1-178.
  3. 1968Cervelle, Bernard, Lévy, Claude, Caye, René (1968) Sur l'inversion du signe de la biréflectance de certains minéraux absorbants : cas de la mawsonite. Bulletin de Minéralogie, 91 (5) 468-478 doi:10.3406/bulmi.1968.6262DOI: 10.3406/bulmi.1968.6262
  4. 1974Lee, M.S., Takenouchi, S., Imai, H. (1974) Occurrence and paragenesis of the Cu Fe-Sn-S minerals, with reference to stannite and stannoidite and mawsonite. Journal of the Mineralogical Society, Japan: 11: 155-164.
  5. 1975Lee, Min Sung, Takenouchi, S., Imai, H. (1975) Syntheses of stannoidite and mawsonite and their genesis in ore deposits. Economic Geology, 70 (4) 834-843 doi:10.2113/gsecongeo.70.4.834DOI: 10.2113/gsecongeo.70.4.834
