Mazorite

Ba3(PO4)2
IMA status
  • Approved
IMA symbol
Mzo
Also known as
  • Mazoriet

Where it forms, where it's found

Geological setting

In rankinite paralava hosted by the massive gehlenite-bearing pyrometamorphic rocks.

xenoliths in volcanic rocks.

Type locality
Mazorite type locality
  1. Hatrurim Basin
  2. Tamar Regional Council
  3. Beersheba Subdistrict
  4. Southern District
  5. Israel

31.1858°, 35.2742°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
colorless
Streak
white
Tenacity
brittle
Cleavage
Distinct/Good

good on (0001)

Fracture
Irregular/Uneven
Density
4.8131 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.76 – 1.766
Surface relief
High
Principal indices
nω 1.760 · nε 1.766
Pleochroism
Non-pleochroic
Extinction
parallel
Notes

strong anisotropy

Michel-Lévy diagramhighlighted lineδ = 0.0060
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]60 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation60 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
R-3m
Cell parameters
a = 5.6617(3) Å · c = 21.170(2) Å
Z
3
Twinning

none

Parting
none
Type-locality form

plate crystals up to 70-100 μm in length but also occurs in small aggregates

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
56BaBariumBarium3137.327411.981
68.45%
8OOxygenOxygen815.999127.992
21.26%
15PPhosphorusPhosphorus230.97461.948
10.29%
Total601.921100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Mazoriet

In other languages

German
IMA 2022-022 · Mazorit
Italian
Mazorite

Classification

Strunz
10th ed.

8.AD

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ADWith only large cationsGroup
  • 8.ADMazoriteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 2022Miyawaki, Ritsuro, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2022) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) – Newsletter 68. European Journal of Mineralogy, 34 (5) 385-391 doi:10.5194/ejm-34-385-2022 DOI: 10.5194/ejm-34-385-2022
  2. 2023Juroszek, Rafał, Krüger, Biljana, Krüger, Hannes, Galuskina, Irina (2023) Minerals with a palmierite-type structure. Part II. Nomenclature and classification of the palmierite supergroup. Mineralogical Magazine, 87 (5) 690-694 doi:10.1180/mgm.2023.56DOI: 10.1180/mgm.2023.56
  3. 2023Krzątała, Arkadiusz, Skrzyńska, Katarzyna, Cametti, Georgia, Galuskina, Irina, Vapnik, Yevgeny, Galuskin, Evgeny (2023) Fluoralforsite, Ba5(PO4)3F – a new apatite-group mineral from the Hatrurim Basin, Negev Desert, Israel. Mineralogical Magazine, 87 (6). 866-877 doi:10.1180/mgm.2023.58 DOI: 10.1180/mgm.2023.58
  4. 2023Juroszek, Rafał, Galuskina, Irina, Krüger, Biljana, Krüger, Hannes, Vapnik, Yevgeny, Kahlenberg, Volker, Galuskin, Evgeny (2023) Minerals with a palmierite-type structure. Part I. Mazorite Ba3(PO4)2, a new mineral from the Hatrurim Complex in Israel. Mineralogical Magazine, 87 (5) 679-689 doi:10.1180/mgm.2023.57DOI: 10.1180/mgm.2023.57
