Mcallisterite

Mg2[B6O7(OH)6]2 · 9H2O
IMA status
  • Approved
IMA symbol
Mcl
Discovered
1963
IMA approved
1963
Also known as
  • IMA1963-012
  • Mcallisteriet
  • Trigonomagneborite

Where it forms, where it's found

Geological setting

Veins in basalt. Alteration of colemannite and priceite.

Type locality
Mott prospect (Mott Colemanite prospect
  1. Mott open cut)
  2. Twenty Mule Team Canyon
  3. Furnace Creek Mining District (Furnace Creek Borate Mining District)
  4. Inyo County
  5. California
  6. USA

36.3958°, -116.7656°

9recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless · white
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

on (0001) and (0112)

Density
1.867 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.459 – 1.504
Surface relief
Low
Principal indices
nω 1.504 · nε 1.459
UV response
Pale yellow
Michel-Lévy diagramhighlighted lineδ = 0.0450
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]450 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation450 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
R-3c
Cell parameters
a = 11.546(1) Å · c = 35.562(5) Å
Z
6
Morphology

Rhombohedral crystals to 12 mm, efforescences .

Type-locality form

Small pellets of clusters of crystals intimately intermixed with ginorite and sassolite. The pellets are typically 1-2 mm, rarely 1 cm. Individual crystals are less than 0.2 mm.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3515.999559.965
72.86%
5BBoronBoron1210.810129.720
16.88%
12MgMagnesiumMagnesium224.30548.610
6.33%
1HHydrogenHydrogen301.00830.240
3.93%
Total768.535100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1963-012
  • Mcallisteriet
  • Trigonomagneborite

In other languages

French
macallistérite · Mcallistérite
German
IMA 1963-012 · Mcallisterit
Spanish
mcallisterita
Italian
Mcallisterite

Classification

Strunz
10th ed.

6.FA.10

  • 6BoratesClass
  • 6.FHexaboratesDivision
  • 6.FANeso-hexaboratesGroup
  • 6.FA.10McallisteriteSpecies
Dana
8th ed.

26.06.02.01

  • 26Hydrated Borates Containing Hydroxyl or HalogenClass
  • 26.06HexaboratesType
  • 26.06.02— unnamed intermediate level —Group
  • 26.06.02.01McallisteriteSpecies
CIM

9.2.14

  • 9BoratesClass
  • 9.2Borates of Be and MgGroup
  • 9.2.14McallisteriteSpecies

Literature, links & citation

Citations
  1. 1940Nikolaev, A.V., Chelishcheva, A.G. (1940) The 25° isotherm of the systems: CaO+B2O3+H2O and MgO+B2O3+H2O. Doklady Akademii Nauk SSSR: 28: 127-130.
  2. 1957Allen, Robert D., Kramer, Henry (1957) Ginorite and sassolite from Death Valley, California. American Mineralogist, 42 (1-2) 56-61
  3. 1957D'Ans, J., Behrendt, K.-H. (1957) Uber die Existenzbedingungen einiger Magnesium Borate. Kali Steinsalz: 2: 121-137.
  4. 1965Schaller, Waldemar T., Vlisidis, Angelina C., Mrose, and Mary E. (1965) Macallisterite, 2MgO·6B2O3·15H2O, a new hydrous magnesium borate mineral from the Death Valley region, Inyo County, California. American Mineralogist, 50 (5-6) 629-640
  5. 1967Aristarain, L. F., Hurlbut, C. S. (1967) Macallisterite, 2MgO·6B2O3·15H2O, from Salta, Argentina. American Mineralogist, 52 (11-12) 1776-1784
