Mcauslanite

Fe2+3Al2(PO4)3(PO3OH)F · 18H2O
IMA status
  • Approved
IMA symbol
Mas
Discovered
1986
IMA approved
1986
Also known as
  • IMA1986-051
  • Mcauslaniet

Where it forms, where it's found

Geological setting

On fracture surfaces in leucomonzogranite at a greisen-hosted tin mine.

Type locality
East Kemptville Tin-Indium Project (East Kemptville Tin Mine)
  1. East Kemptville
  2. Argyle
  3. Yarmouth Co.
  4. Nova Scotia
  5. Canada

44.1031°, -65.6808°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Yellowish white
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

Parallel to [001] good

Density
2.22 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 55° · 2V calc = 60°
Refractive index
1.522 – 1.534
Surface relief
Moderate
Principal indices
nα 1.522 · nβ 1.531 · nγ 1.534
Pleochroism
Non-pleochroic
Dispersion
none
Extinction
X:b= l7° in β obtuse Y:c = l8° in α obtuse Z:a = 14° in γ obtuse
UV response
Not fluorescent
Michel-Lévy diagramhighlighted lineδ = 0.0120
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]120 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation120 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Cell parameters
a = 10.055(5) Å · b = 11.568(5) Å · c = 6.888(5) Å
Cell angles
α = 105.84(6) ° · β = 93.66(6) ° · γ = 106.47(5) °
Ratio a:b:c
1 : 1.150 : 0.685
Z
1
Morphology

Tabular to acicular fibers and bladed crystals. Individuals blades are terminated by the forms (010) major, (100) minor and (001) very minor.

Twinning

Twinning occurs as a l80 deg rotation about a*. The (010) face has a twin suture.

Type-locality form

Clusters of radiating crystals to 4 mm The crystals are clear, tabular to acicular yellowish-white fibers and bladed crystals.

Comment

Point Group: _1 or 1; Space Group: P_1 or P1.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3415.999543.966
57.52%
26FeIronIron355.845167.535
17.72%
15PPhosphorusPhosphorus430.974123.896
13.10%
13AlAluminiumAluminium226.98253.964
5.71%
1HHydrogenHydrogen371.00837.296
3.94%
9FFluorineFluorine118.99818.998
2.01%
Total945.655100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1986-051
  • Mcauslaniet

In other languages

German
IMA 1986-051 · Mcauslanit
Italian
Mcauslanite

Classification

Strunz
10th ed.

8.DB.60

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DBWith only medium-sized cations, (OH, etc.):RO4< 1:1Group
  • 8.DB.60McauslaniteSpecies
Dana
8th ed.

42.11.22.01

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.11(AB)3(XO4)2Zq·xH2OType
  • 42.11.22— unnamed intermediate level —Group
  • 42.11.22.01McauslaniteSpecies
CIM

22.1.26

  • 22Phosphates, Arsenates or Vanadates with other AnionsClass
  • 22.1Phosphates, arsenates or vanadates with fluorideGroup
  • 22.1.26McauslaniteSpecies

Literature, links & citation

Citations
  1. 1988Richardson, J. M., Roberts, A. C., Grice, J. D., Ramik, R. A. (1988) Mcauslanite, a supergene hydrated iron aluminum fluorophosphate from the East Kemptville tin mine, Yarmouth County, Nova Scotia. The Canadian Mineralogist, 26 (4) 917-921
  2. 1990Jambor, John L., Vanko, David A. (1990) New Mineral Names. American Mineralogist, 75 (5-6) 706-713
  3. 2005(2005) Mcauslanite. Handbook of Mineralogy. Mineralogical Society of America
