Melanostibite

Mn2Fe3+Sb5+O6
IMA status
  • Approved
  • Grandfathered
IMA symbol
Mlsb
Discovered
1892
Also known as
  • Melanostibian
  • Melanostibiet

Where it forms, where it's found

Geological setting

Fe–Mn orebody in manganoan dolomite.

Type locality
Sjögruvan
  1. Grythyttan
  2. Hällefors
  3. Örebro County
  4. Sweden

59.6685°, 14.6079°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Black · reddish-black
Streak
Pale red to cherry red
Tenacity
brittle
Cleavage
Perfect

(0001)

Density
5.24 g/cm³

Optical

Optical type
Uniaxial
Refractive index
2.12
Surface relief
Very high
Principal indices
nβ 2.12

Crystallography

Crystal system
Trigonal
Space group
#78
Cell parameters
a = 5.2351(3) Å · c = 14.3645(8) Å
Z
3
Morphology

pseudohexagonal tabular crystals

Twinning

Common. Rotation about [0001].

Type-locality form

thin mm-sized black platelets

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
51SbAntimonyAntimony1121.760121.760
31.75%
25MnManganeseManganese254.938109.876
28.65%
8OOxygenOxygen615.99995.994
25.03%
26FeIronIron155.84555.845
14.57%
Total383.475100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Melanostibian
  • Melanostibiet

In other languages

German
Melanostibit
Italian
Melanostibite

Classification

Strunz
10th ed.

4.CB.05

  • 4OxidesClass
  • 4.CMetal: Oxygen = 2: 3,3: 5, and similarDivision
  • 4.CBWith medium-sized cationsGroup
  • 4.CB.05MelanostibiteSpecies
Dana
8th ed.

04.03.05.05

  • 04Simple OxidesClass
  • 04.03A2X3Type
  • 04.03.05Ilmenite GroupGroup
  • 04.03.05.05MelanostibiteSpecies

Literature, links & citation

Citations
  1. 1893Igelström, L.J. (1893) Melanostibian, ein neues mineral von der Manganerzgrube Sjögrufvan, Kirchspiel Grythyttan, Gouvernement Örebro, Schweden. Zeitschrift für Krystallographie und Mineralogie: 21: 246-248.
  2. 1968Moore, Paul B. (1968) Substitutions of the type (Sb5+0.5Fe3+0.5)<->(Ti4+): The crystal structure of melanostibite. American Mineralogist, 53 (7-8) 1104-1109
  3. 1968Fleischer, Michael (1968) New Mineral Names. American Mineralogist, 53 (9-10) 1775-1780
  4. 1968Moore, P.B (1968) Contributions to Swedish Mineralogy II. Melanostibite and manganostibite, two unusual antimony minerals. The identity of ferrostibian with långbanite. Arkiv för Mineralogi och Geologi, 4 (5, nr 23). 449-458
  5. 1969Welin, E. (1969) Notes on the mineralogy of Sweden 6. X-ray powder data for minerals from Långban and the related mineral deposits of Central Sweden. Arkiv för Mineralogi och Geologi, 4 (6, nr 30). 499-541
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Melanostibite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/melanostibite-2631},
  note      = {Accessed 2026-05-11}
}
