Mendipite

Pb3O2Cl2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Mdi
Discovered
1839
Also known as
  • Berzélite (of Lévy)
  • Cerasine
  • Cerasite (of Breithaupt)
  • +14 more

Where it forms, where it's found

Type locality
Mendip Hills National Landscape
  1. Somerset
  2. England
  3. UK
15recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless · white · grey · often tinged yellow · blue · red · nearly colourless in transmitted light
Streak
White
Cleavage
Perfect

On (110) perfect; (100) and (010) less perfect.

Fracture
Irregular/Uneven · Conchoidal
Density
7.24 g/cm³

Optical

Optical type
Biaxial (+/-) · 2V measured = 90° · 2V calc = 84°
Refractive index
2.24 – 2.31
Surface relief
Very high
Principal indices
nα 2.24 · nβ 2.27 · nγ 2.31
Dispersion
relatively strong
Extinction
Parallel. X = a; Y = b; Z = c.
Michel-Lévy diagramhighlighted lineδ = 0.0700
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]700 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation700 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#44
Cell parameters
a = 9.52 Å · b = 11.87 Å · c = 5.87 Å
Ratio a:b:c
1 : 1.247 : 0.617
Z
4
Morphology

Fibrous or columnar masses, often radiated.

Type-locality form

Radiating masses of pale straw-yellow prismatic crystals and cleavages.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead3207.200621.600
85.80%
17ClChlorineChlorine235.45070.900
9.78%
8OOxygenOxygen215.99931.998
4.42%
Total724.498100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Berzélite (of Lévy)
  • Cerasine
  • Cerasite (of Breithaupt)
  • Chlor-Spath
  • Chloride of Lead
  • Churchillit
  • Churchillita
  • Churchillite
  • Flaky and Striated Lead-ore
  • Mendipiet
  • Minera plumbi calciformis
  • Muriate of Lead
  • Peritomous Lead-baryte
  • Plomb chloruré
  • Pseudomendipite
  • Saltsyradt Bly
  • Salzsaures Blei

In other languages

German
Mendipit
Italian
mendipite

Classification

Strunz
10th ed.

3.DC.70

  • 3HalidesClass
  • 3.DOxyhalides, hydroxyhalides and related double halidesDivision
  • 3.DCWith Pb (As,Sb,Bi), without CuGroup
  • 3.DC.70MendipiteSpecies
Dana
8th ed.

10.03.01.01

  • 10Oxyhalides and HydroxyhalidesClass
  • 10.03A3(O,OH)2XqType
  • 10.03.01— unnamed intermediate level —Group
  • 10.03.01.01MendipiteSpecies
CIM

8.8.5

  • 8Halides - Fluorides, Chlorides, Bromides and Iodides; also Fluoborates and FluosilicatesClass
  • 8.8Halides of PbGroup
  • 8.8.5MendipiteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1823Berzelius, Jac (1823) Undersökning af tvenne i K. Vet. Academiens Mineralsamling befintliga Mineralier [Examination of two minerals in the Mineral Collection of the Royal Swedish Academy of Sciences]. Kungliga Svenska vetenskapsakademiens handlingar, S. 3 Vol. 11. 183-189
  2. 1824Berzelius (1824) Edinburgh Journal of Science: 1: 379.
  3. 1825Mohs, Frederick; Haidinger, William (1825) Treatise on Mineralogy Vol. 2.
  4. 1832Breithaupt, A. (1832) Vollständige Characteristik etc. 2nd. Ed.: 61 (as Chlor-Spath).
  5. 1832Beudant, François-Sulpice (1832) Traité élémentaire de minéralogie. Deuxiéme Edition [Elementary Treatise on Mineralogy. Second Edition] (2nd ed.) Vol. 2 - Tome II [Volume II]. Chez Verdière.
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Mendipite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/mendipite-2641},
  note      = {Accessed 2026-05-11}
}
