Metavauxite

Fe2+Al2(PO4)2(OH)2 · 8H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Mvx
Discovered
1927
Also known as
  • Metavauxiet

Where it forms, where it's found

Geological setting

Oxidized zone of tin veins.

Type locality
Siglo Veinte Mine
  1. Llallagua
  2. Rafael Bustillo Province
  3. Potosí
  4. Bolivia

-18.4229°, -66.5925°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless · white · light green · colourless in transmitted light.
Streak
White
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
2.345 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 75 – 90°
Refractive index
1.55 – 1.577
Surface relief
Moderate
Principal indices
nα 1.550 · nβ 1.561 · nγ 1.577
Pleochroism
Non-pleochroic
Dispersion
r < v strong
Extinction
0.027
UV response
Not fluorescent in UV
Michel-Lévy diagramhighlighted lineδ = 0.0270
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]270 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation270 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P1 21/c 1
Cell parameters
a = 10.22 Å · b = 9.56 Å · c = 6.94 Å
Cell angles
β = 97.87 °
Ratio a:b:c
1 : 0.935 : 0.679
Z
2
Morphology

Crystals prismatic to acicular, elongated [001], exhibiting forms (100), (110), (101), (111), and (211). Commonly in subparallel to radial aggregates.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1815.999287.982
60.26%
15PPhosphorusPhosphorus230.97461.948
12.96%
26FeIronIron155.84555.845
11.69%
13AlAluminiumAluminium226.98253.964
11.29%
1HHydrogenHydrogen181.00818.144
3.80%
Total477.883100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Metavauxiet

In other languages

German
Metavauxit
Spanish
Metavauxita
Italian
Metavauxite
Russian
Метавоксит

Classification

Strunz
10th ed.

8.DC.25

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DCWith only medium-sized cations, (OH, etc.):RO4 = 1:1 and < 2:1Group
  • 8.DC.25MetavauxiteSpecies
Dana
8th ed.

42.11.11.01

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.11(AB)3(XO4)2Zq·xH2OType
  • 42.11.11— unnamed intermediate level —Group
  • 42.11.11.01MetavauxiteSpecies
CIM

19.14.24

  • 19PhosphatesClass
  • 19.14Phosphates of Fe and other metalsGroup
  • 19.14.24MetavauxiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1927Gordon (1927) American Mineralogist: 12: 264.
  2. 1933Peacock, M. A. (1933) On Bismuthinite. Zeitschrift für Kristallographie, 86 (1-6). 203-211 doi:10.1524/zkri.1933.86.1.203DOI: 10.1524/zkri.1933.86.1.203
  3. 1944Gordon, Samuel G. (1944) The mineralogy of the tin mines of Cerro de Llallagua, Bolivia. Proceedings of the Academy of Natural Sciences of Philadelphia, 96. 279-359
  4. 1967Baur, W.H. and B. Rama Rao (1967) The crystal structure of metavauxite. Naturwiss., 51, 561.
  5. 1975Moore, P.B. (1975): Laueite, pseudolaueite, stewartite and metavauxite; a study in combinatorial polymorphism. Neues Jahrbuch für Mineralogie, Abhandlungen: 123: 148-159.
