Meurigite-K

KFe3+8(PO4)6(OH)7 · 6.5H2O
IMA status
  • Approved
IMA symbol
Meu-K
Discovered
1995
IMA approved
1995
Also known as
  • IMA1995-022
  • Meurigiet-K
  • Potassian Kidwellite

Where it forms, where it's found

Geological setting

Oxide zone of a copper deposit.

Type locality
Chino Mine (Santa Rita pit
  1. Santa Rita Mine)
  2. Santa Rita
  3. Santa Rita Mining District
  4. Grant County
  5. New Mexico
  6. USA

32.7900°, -108.0673°

19recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Silky
Transparency
Translucent
Colour
Yellowish brown · cream to white · pale to canary yellow
Streak
White
Tenacity
brittle
Cleavage
Perfect

(001)

Fracture
None observed
Density
2.96 g/cm³

Optical

Optical type
Biaxial (+) · 2V calc = 60°
Refractive index
1.78 – 1.8
Surface relief
High
Principal indices
nα 1.780 · nβ 1.785 · nγ 1.800
Birefringence
0.020
Pleochroism
Non-pleochroic
Dispersion
r > v distinct
UV response
Not fluorescent in UV
Michel-Lévy diagramhighlighted lineδ = 0.0200
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]200 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation200 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#10
Cell parameters
a = 29.018(5) Å · b = 5.1892(6) Å · c = 19.695(3) Å
Cell angles
β = 106.987(1) °
Ratio a:b:c
1 : 0.179 : 0.679
Unit cell volume
2836.3 ų
Z
4
Morphology

Tabular on [001] and elongated parallel to [010].

Type-locality form

Drusy coating of fibrous yellow rosettes.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen37.515.999599.962
46.44%
26FeIronIron855.845446.760
34.58%
15PPhosphorusPhosphorus630.974185.844
14.39%
19KPotassiumPotassium139.09839.098
3.03%
1HHydrogenHydrogen201.00820.160
1.56%
Total1291.824100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1995-022
  • Meurigiet-K
  • Potassian Kidwellite

In other languages

German
IMA 1995-022 · Meurigit-K
Italian
Meurigite · Meurigite-K

Classification

Strunz
10th ed.

8.DJ.20

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DJWith large and medium-sized cations, (OH, etc.):RO4 = 1:1Group
  • 8.DJ.20Meurigite-KSpecies
Dana
8th ed.

42.13.14.01

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.13MiscellaneousType
  • 42.13.14— unnamed intermediate level —Group
  • 42.13.14.01Meurigite-KSpecies

Literature, links & citation

Citations
  1. 1996Birch, W. D., Pring, A., Self, P. G., Gibbs, R. B., Keck, E., Jensen, M. C. and Foord, E. E. (1996): Meurigite, a new fibrous iron phosphate resembling kidwellite. Mineralogical Magazine, 60, 787-793.
  2. 1997Mandarino, Joseph A. (1997) Abstracts of New Mineral Descriptions. The Mineralogical Record, 28 (2) 141-145
  3. 1999Kolitsch, U. (1999): Evidence for the identity of meurigite and phosphofibrite by transmission electron microscopy and X-ray powder diffraction. European Journal of Mineralogy: 11, Beih. no.1, 132.
  4. 2007Kampf, A. R., Pluth, J. J., Chen, Y.-S. (2007) The crystal structure of meurigite. American Mineralogist, 92 (8) 1518-1524 doi:10.2138/am.2007.2486 DOI: 10.2138/am.2007.2486
  5. 2008Kampf, A.R., Kolitsch, U. (2008): The relationship between phosphofibrite and meurigite. M&M6, 6th Intern. Conf. on Mineralogy & Museums, Colorado School of Mines, Golden, Colorado, USA, September 7-9, 2008; Program and Abstract Volume, 26.
