Mieite-(Y)

Y4Ti(SiO4)2O[F,(OH)]6
IMA status
  • Approved
IMA symbol
Mi-Y
IMA approved
2014
Also known as
  • IMA2014-020
  • Mieiet-(Y)

Where it forms, where it's found

Geological setting

Pegmatite

Type locality
Unnamed pegmatite
  1. Yunoyama-onsen
  2. Komono town
  3. Mie District
  4. Mie Prefecture
  5. Japan

35.0097°, 136.4592°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Pale amber yellow
Streak
White
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
4.61 g/cm³

Optical

Optical type
Biaxial
Refractive index
1.694 – 1.715
Surface relief
High
Principal indices
nα 1.694 · nγ 1.715
Pleochroism
Non-pleochroic

anomalous blue interference colors

Michel-Lévy diagramhighlighted lineδ = 0.0210
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]210 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation210 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Cmcm
Cell parameters
a = 14.942(2) Å · b = 10.633(2) Å · c = 7.0365(8) Å
Ratio a:b:c
1 : 0.712 : 0.471
Unit cell volume
1100.3 ų
Z
4
Type-locality form

Amber yellow mass about 1cm.

Comment

From raw - not annealed material.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
39YYttriumYttrium488.906355.624
43.38%
8OOxygenOxygen1515.999239.985
29.28%
9FFluorineFluorine618.998113.988
13.91%
14SiSiliconSilicon228.08556.170
6.85%
22TiTitaniumTitanium147.86747.867
5.84%
1HHydrogenHydrogen61.0086.048
0.74%
Total819.682100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2014-020
  • Mieiet-(Y)

In other languages

German
IMA 2014-020 · Mieit-(Y)
Italian
mieite(Y)

Classification

Strunz
10th ed.

9.AG.25

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AGNesosilicates with additional anions; cations in > [6] +- [6] coordinationGroup
  • 9.AG.25Mieite-(Y)Species
Dana
8th ed.

52.04.04.03

  • 52Nesosilicates Insular Sio4 Groups and O, Oh, F, H2oClass
  • 52.04Insular SiO4 Groups and O, OH, F, and H2O with cations in [6] and/or >[6] coordinationType
  • 52.04.04Natisite - Yftisite groupGroup
  • 52.04.04.03Mieite-(Y)Species

Literature, links & citation

Citations
  1. 2015Miyawaki, Ritsuro, Matsubara, Satoshi, Yokoyama, Kazumi, Shigeoka, Masako, Momma, Koichi, Yamamoto, Sadaoki (2015) Mieite–(Y), Y4Ti(SiO4)2O[F,(OH)]6, a new mineral in a pegmatite at Souri Valley, Komono, Mie Prefecture, central Japan. Journal of Mineralogical and Petrological Sciences, 110 (3) 135-144 doi:10.2465/jmps.150106 DOI: 10.2465/jmps.150106
  2. 2016(2016) Mieite-(Y). Handbook of Mineralogy. Mineralogical Society of America
  3. 2016Cámara, Fernando, Belakovskiy, Dmitriy (2016) New Mineral Names. American Mineralogist, 101 (3) 748-751 doi:10.2138/am-2016-nmn101317DOI: 10.2138/am-2016-nmn101317
