Mikasaite

Fe3+2(SO4)3
IMA status
  • Approved
IMA symbol
Mik
Discovered
1994
Also known as
  • IMA1992-015
  • Mikasaiet

Where it forms, where it's found

Geological setting

From fracture near burning coal seam.

Type locality
Ikushunbetsu
  1. Mikasa City
  2. Sorachi Subprefecture
  3. Hokkaidō Prefecture
  4. Japan

43.2208°, 142.1619°

9recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Dull
Colour
White to light brown
Streak
White to light brown
Density
3.06 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.504 – 1.518
Surface relief
Moderate
Principal indices
nω 1.504 · nε 1.518
Michel-Lévy diagramhighlighted lineδ = 0.0140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]140 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation140 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#80
Cell parameters
a = 8.14(1) Å · c = 21.99(8) Å
Z
6
Type-locality form

Aggregates of porous spherical crystals.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1215.999191.988
48.02%
26FeIronIron255.845111.690
27.93%
16SSulfurSulfur332.06096.180
24.05%
Total399.858100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mn

Synonyms

  • IMA1992-015
  • Mikasaiet

In other languages

German
IMA 1992-015 · Mikasait
Italian
Mikasaite
Japanese
三笠石

Classification

Strunz
10th ed.

7.AB.05

  • 7SulfatesClass
  • 7.ASulfates (selenates, etc.) without additional anions, without H2ODivision
  • 7.ABWith medium-sized cationsGroup
  • 7.AB.05MikasaiteSpecies
Dana
8th ed.

28.04.05.02

  • 28Anhydrous Acid and Normal SulfatesClass
  • 28.04MiscellaneousType
  • 28.04.05— unnamed intermediate level —Group
  • 28.04.05.02MikasaiteSpecies

Literature, links & citation

Citations
  1. 1973Masse, René, Guitel, Jean-Claude, Perret, René (1973) Structure cristalline de la variété rhomboédrique du sulfate ferrique Fe2(SO4)3. Bulletin de Minéralogie, 96 (6) 346-349 doi:10.3406/bulmi.1973.6846DOI: 10.3406/bulmi.1973.6846
  2. 1976Christidis, P. C., Rentzeperis, P. J. (1976) The crystal structure of rhombohedral Fe2(SO4)3. Zeitschrift für Kristallographie, 144 (1). 341-352 doi:10.1524/zkri.1976.144.1-6.341 DOI: 10.1524/zkri.1976.144.1-6.341
  3. 1994Miura, Hiroyuki, Niida, Kiyoaki, Hirama, Tadao (1994) Mikasaite, (Fe3+, Al)2(SO4)3, a new ferric sulphate mineral from Mikasa city, Hokkaido, Japan. Mineralogical Magazine, 58 (393) 649-653 doi:10.1180/minmag.1994.058.393.15 DOI: 10.1180/minmag.1994.058.393.15
  4. 1995Jambor, John L., Pertsev, Nikolai N., Roberts, Andrew C. (1995) New Mineral Names. American Mineralogist, 80 (7-8). 845-850
  5. 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
