Miserite

K1.5-x(Ca,Y,REE)5[Si6O15][Si2O7](OH,F)2 · yH2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Mis
Discovered
1950
Also known as
  • Miseriet
  • Natroxonotlite

Where it forms, where it's found

Geological setting

Contact metamorphosed shale, due to a dike of nepheline syenite.

Type locality
North Wilson pit
  1. Union Carbide Mine
  2. Wilson Springs (Potash Sulfur Springs)
  3. Garland County
  4. Arkansas
  5. USA

34.4778°, -92.9681°

7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Pink · red-brown · raspberry-red
Streak
White
Cleavage
Perfect

Perfect on (100), imperfect on (010).

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
2.84 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 65 – 86° · 2V calc = 65 – 87°
Refractive index
1.587 – 1.594
Surface relief
Moderate
Principal indices
nα 1.587 · nβ 1.589 · nγ 1.594
Dispersion
Weak, r > v
Notes

Z ≈ a on (100); Y ∧ c ≈ 2° on (100); Y ∧ c = 11° on (010)

Michel-Lévy diagramhighlighted lineδ = 0.0070
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]70 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation70 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Cell parameters
a = 10.120(3) Å · b = 16.079(3) Å · c = 7.378(3) Å
Cell angles
α = 96.62(2) ° · β = 111.15(2) ° · γ = 76.33(2) °
Ratio a:b:c
1 : 1.589 : 0.729
Unit cell volume
1087 ų
Z
2
Twinning

Lamellar

Type-locality form

Fine-grained fibrous. Compact aggregates form slightly curved, scaly masses several centimeters in diameter and less than than 5 mm thick.

Comment

Refined, Rozhdestvenskaya and Evdominkov (2006)

Crystal structure

Chemical composition

Impurities
  • Al
  • Y
  • TR
  • La
  • Pr
  • Nd
  • Eu
  • Dy
  • Er
  • Tm
  • Yb
  • Lu
  • Fe
  • Mn

Synonyms

  • Miseriet
  • Natroxonotlite

In other languages

German
Miserit
Italian
miserite

Classification

Strunz
10th ed.

9.DG.85

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DGInosilicates with 3-periodic single and multiple chainsGroup
  • 9.DG.85MiseriteSpecies
Dana
8th ed.

70.02.01.01

  • 70Inosilicates Column or Tube StructuresClass
  • 70.02Column or Tube Structures with Si2O7 dimersType
  • 70.02.01— unnamed intermediate level —Group
  • 70.02.01.01MiseriteSpecies
CIM

14.6.8

  • 14Silicates not Containing AluminumClass
  • 14.6Silicates of Ca with alkali or Mg or bothGroup
  • 14.6.8MiseriteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1950Schaller, Waldemar T. (1950) Miserite from Arkansas: a renaming of natroxonotlite. American Mineralogist, 35 (9-10) 911-921
  2. 1972Berry, I.G., Lin, H.-C., Davis, G.C. (1972) A new occurrence of miserite from the Kipawa Lake area, Temiscamingue Co., Quebec. The Canadian Mineralogist: 11: 569. (Abstract)
  3. 1976Scott, J.D. (1976) Crystal structure of miserite, a Zoltai type 5 structure. The Canadian Mineralogist: 14: 515-528.
  4. 1987Rozhdestvenskaya, I. V.; Nikishova, L. V.; Bannova, I. I.; Lasebnik, Yu. D. (1987) Canasite: the refinement of crystal structure and comparison with that of miserite. Acta Crystallographica Section A Foundations of Crystallography, 43 (a1). C159 doi:10.1107/s0108767387081212DOI: 10.1107/s0108767387081212
  5. 1990Horváth, László, Gault, Robert A. (1990) The Mineralogy of Mont Saint-Hilaire, Quebec. The Mineralogical Record, 21 (4) 281-359
