Moctezumite

Pb(UO2)(Te4+O3)2
IMA status
  • Approved
IMA symbol
Moc
Discovered
1961
Also known as
  • IMA1965-004
  • Moctezumiet

Where it forms, where it's found

Geological setting

Tellurium-gold deposit

Type locality
Moctezuma Mine
  1. Moctezuma
  2. Moctezuma Municipality
  3. Sonora
  4. Mexico

29.6942°, -109.7125°

3recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Bright orange · brownish orange to dark orange.

Brownish orange in crystals that have been slightly altered

Cleavage
Perfect

(100)

Density
5.73 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 5 – 10°
Refractive index
2.11
Surface relief
Very high
Principal indices
nα 2.11 · nβ 2.11 · nγ 2.11
Notes

RIs are minimums

Michel-Lévy diagramhighlighted lineδ = 0.0000
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]0 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation0 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 7.813(5) Å · b = 7.061(2) Å · c = 13.775(4) Å
Cell angles
β = 93.71(2) °
Ratio a:b:c
1 : 0.904 : 1.763
Z
4
Morphology

Blade like

Type-locality form

Minute blades and rosettes in cracks and vugs in oxidized ore zone.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
52TeTelluriumTellurium2127.600255.200
30.81%
92UUraniumUranium1238.029238.029
28.73%
82PbLeadLead1207.200207.200
25.01%
8OOxygenOxygen815.999127.992
15.45%
Total828.421100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1965-004
  • Moctezumiet

In other languages

German
IMA 1965-004 · Moctezumit
Spanish
Moctezumita
Italian
Moctezumite

Classification

Strunz
10th ed.

4.JK.65

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JKTellurites without additional anions, without H2OGroup
  • 4.JK.65MoctezumiteSpecies
Dana
8th ed.

34.01.05.01

  • 34Selenites, Tellurites and SulfitesClass
  • 34.01A(XO3)Type
  • 34.01.05— unnamed intermediate level —Group
  • 34.01.05.01MoctezumiteSpecies
CIM

28.3.20

  • 28Selenites, Selenates, Tellurites, and TelluratesClass
  • 28.3TelluritesGroup
  • 28.3.20MoctezumiteSpecies

Literature, links & citation

Citations
  1. 1965Gaines, Richard V. (1965) Moctezumite, a new lead uranyl tellurite. American Mineralogist, 50 (9) 1158-1163
  2. 1981Brandstätter, F. (1981) Synthesis and crystal structure determination, of Pb2[UO2][TeO3]3. Zeitschrift für Kristallographie: 155: 193-200.
  3. 1993Swihart, George H., Gupta, Pradip K. Sen, Schlemper, Elmer O., Back, Malcolm E., Gaines, Richard V. (1993) The crystal structure of moctezumite [PbUO2](TeO3)2. American Mineralogist, 78 (7-8) 835-839
  4. 2005(2005) Moctezumite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2005Burns, Peter C. (2005) U6+ minerals and inorganic compounds: insights into an expanded structural hierarchy of crystal structures. The Canadian Mineralogist, 43 (6) 1839-1894 doi:10.2113/gscanmin.43.6.1839 DOI: 10.2113/gscanmin.43.6.1839
