Molybdophyllite

Pb8Mg9[Si10O28(OH)8O2(CO3)3] · H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Mdp
Discovered
1901
Also known as
  • Molybdophylliet
  • Molybdophyllita

Where it forms, where it's found

Type locality
Långban Mine
  1. Långban Ore District
  2. Filipstad
  3. Värmland County
  4. Sweden

59.8554°, 14.2648°

4recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless · pale grey · pale yellow · very pale green
Streak
White
Tenacity
flexible
Cleavage
Perfect

Parallel to the pseudohexagonal (0001) plane.

Only a little more brittle than mica.

Fracture
Irregular/Uneven
Density
4.652 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 5 – 10°
Notes

Pseudo-uniaxial (-) optics: ω = 1.815, ε = 1.761. Modern optical analysis given in Kolitsch et al. (2012).

Crystallography

Crystal system
Monoclinic
Space group
C2
Cell parameters
a = 16.232(6) Å · b = 9.373(2) Å · c = 14.060(3) Å
Cell angles
β = 97.36 °
Ratio a:b:c
1 : 0.577 : 0.866
Unit cell volume
2121.5 ų
Z
2
Morphology

Platy aggregates, embedded in matrix.

Comment

Pseudohexagonal.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead8207.2001657.600
55.79%
8OOxygenOxygen4815.999767.952
25.85%
14SiSiliconSilicon1028.085280.850
9.45%
12MgMagnesiumMagnesium924.305218.745
7.36%
6CCarbonCarbon312.01136.033
1.21%
1HHydrogenHydrogen101.00810.080
0.34%
Total2971.260100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Na
  • K
  • H2O

Synonyms

  • Molybdophylliet
  • Molybdophyllita

In other languages

German
Molybdophyllit
Italian
Molibdofillite
Russian
молибдофиллит

Classification

Strunz
10th ed.

9.HH.25

  • 9SilicatesClass
  • 9.HUnclassified silicatesDivision
  • 9.HHWith PbGroup
  • 9.HH.25MolybdophylliteSpecies
Dana
8th ed.

78.05.07.01

  • 78Unclassified SilicatesClass
  • 78.05Unclassified silicates possible phyllosilicatesType
  • 78.05.07— unnamed intermediate level —Group
  • 78.05.07.01MolybdophylliteSpecies
CIM

14.13.4

  • 14Silicates not Containing AluminumClass
  • 14.13Silicates of PbGroup
  • 14.13.4MolybdophylliteSpecies

Literature, links & citation

Citations
  1. 1901Flink, G. (1901): Mineralogische Notizen. Bulletin of the Geological Institution of the University of Uppsala, 5, 81-96.
  2. 1918Aminoff, G. (1918) Röntgenographische Ermittelung der Symmetrie und des Elementes po des Molybdophyllits. Geologiska Föreningen i Stockholm Förhandlingar, 40 (7) 923-938 doi:10.1080/11035891809444851DOI: 10.1080/11035891809444851
  3. 1988Charalampides, G. and Lindqvist, B. (1988): Ganomalite, margarosanite and molybdophyllite from Långban, south-central Sweden, and synthetic equivalents. Meddelanden från Stockholms Universitets Geologiska Institution, 273, IV/1-IV/24.
  4. 1994Charalampides, G. (1994): Mineralogical and crystal-chemical data of the lead silicate species ganomalite, margarosanite, and molybdophyllite from Långban, south-central Sweden and their synthetic equivalents. Oryktos Ploutos, 91, 33-46.
  5. 1996Jambor, J.L., Pertsev, N.N., Roberts, A.C. (1996) New mineral names. American Mineralogist: 81: 516-520.
