Montbrayite

(Au,Ag,Sb,Bi,Pb)23(Te,Sb,Bi,Pb)38
IMA status
  • Approved
  • Grandfathered
IMA symbol
Mnb
Discovered
1945
Also known as
  • Montbrayiet

Where it forms, where it's found

Type locality
Robb-Montbray Mine
  1. Rouyn-Noranda TE
  2. Abitibi-Témiscamingue
  3. Québec
  4. Canada

48.3083°, -79.3272°

26recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour

Very light yellow

Tenacity
very brittle
Cleavage
Very Good

(110), (011), 111

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
9.94 g/cm³

Optical

Pleochroism
Weak

Light gray, yellowish brown, bluish gray

Optical colour
pale yellow
Anisotropism
Weak
Internal reflections
none
UV response
Not fluorescent in UV
Notes

Strong anisotropy from Toburu mine

Crystallography

Crystal system
Triclinic
Space group
#1
Cell parameters
a = 12.11 Å · b = 13.44 Å · c = 10.80 Å
Cell angles
α = 104.38 ° · β = 97.50 ° · γ = 107.93 °
Ratio a:b:c
1 : 1.110 : 0.892
Z
12
Morphology

Crystals very rare

Twinning

Observed

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth61208.98012747.780
28.54%
82PbLeadLead61207.20012639.200
28.29%
51SbAntimonyAntimony61121.7607427.360
16.63%
52TeTelluriumTellurium38127.6004848.800
10.85%
79AuGoldGold23196.9674530.241
10.14%
47AgSilverSilver23107.8682480.964
5.55%
Total44674.345100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ag
  • Pb
  • Bi
  • S

Synonyms

  • Montbrayiet

In other languages

German
IMA 17-F · Montbrayit
Italian
Montbrayite
Russian
Монтбрейит

Classification

Strunz
10th ed.

2.DB.20

  • 2Sulfides and SulfosaltsClass
  • 2.DMetal Sulfides, M: S = 3 :4 and 2:3Division
  • 2.DBM:S = 2:3Group
  • 2.DB.20MontbrayiteSpecies
Dana
8th ed.

02.11.08.01

  • 02SulfidesClass
  • 02.11AmBnXp, with (m+n):p = 2:3Type
  • 02.11.08— unnamed intermediate level —Group
  • 02.11.08.01MontbrayiteSpecies
CIM

3.3.14

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.3Sulphides etc. of AuGroup
  • 3.3.14MontbrayiteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1946Peacock, M. A., Thompson, R. M. (1946) Montbrayite, a new gold telluride. American Mineralogist, 31 (11-12) 515-526
  2. 1949Thompson, R. M. (1949) The telluride minerals and their occurrence in Canada. American Mineralogist, 34 (5-6) 341-382
  3. 1969Rucklidge, J. (1969): Frohbergite, montbrayite, and a new Pb-Bi telluride. Can. Mineral. 9, 709-716.
  4. 1971BACHECHI, F. (1971) Crystal Structure of Montbrayite. Nature Physical Science, 231. 67-68 doi:10.1038/physci231067a0DOI: 10.1038/physci231067a0
  5. 1972Bachechi, F. (1972) Synthesis and stability of montbrayite, Au2Te3. American Mineralogist, 57 (1-2) 146-154
