Moydite-(Y)

YB(OH)4(CO3)
IMA status
  • Approved
IMA symbol
Moy-Y
Discovered
1985
IMA approved
1985
Also known as
  • IMA1985-025
  • Moydiet-(Y)

Where it forms, where it's found

Geological setting

Granite pegmatite rich in rare earth minerals.

Type locality
Evans-Lou Mine
  1. Lake Saint-Pierre
  2. Saint-Pierre-de-Wakefield
  3. Val-des-Monts
  4. Les Collines-de-l'Outaouais RCM
  5. Outaouais
  6. Québec
  7. Canada

45.7611°, -75.7015°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101 – 2/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Yellow · also colorless
Streak
Pale yellow to colorless
Tenacity
brittle
Cleavage
Distinct/Good

(010) good; (101) poor

Fracture
Conchoidal
Density
3.133 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 32° · 2V calc = 34°
Refractive index
1.588 – 1.69
Surface relief
Moderate
Principal indices
nα 1.588 · nβ 1.681 · nγ 1.690
Birefringence
0.102
Pleochroism
Non-pleochroic
Dispersion
relatively strong
Extinction
Parallel. X = b; Y = a; Z = c.
UV response
Not fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.1020
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1020 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1020 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Pbca
Cell parameters
a = 9.089 Å · b = 12.244 Å · c = 8.926 Å
Ratio a:b:c
1 : 1.347 : 0.982
Z
8
Morphology

Type material: Platy basal pinacoid (010) modified by the rhombic dipyramid (111) and, occasionally, a minor development of pinacoids (100) and (001).

Type-locality form

Yellow bladed gemmy crystals to 1 mm+.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen715.999111.993
49.17%
39YYttriumYttrium188.90688.906
39.04%
6CCarbonCarbon112.01112.011
5.27%
5BBoronBoron110.81010.810
4.75%
1HHydrogenHydrogen41.0084.032
1.77%
Total227.752100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • REE

Synonyms

  • IMA1985-025
  • Moydiet-(Y)

In other languages

German
IMA 1985-025 · Moydit-(Y)
Italian
Moydite- · Moydite-(Y)

Classification

Strunz
10th ed.

6.AC.45

  • 6BoratesClass
  • 6.AMonoboratesDivision
  • 6.ACB(O,OH)4, without and with additional anions; 1(T), 1(T)+OH, etcGroup
  • 6.AC.45Moydite-(Y)Species
Dana
8th ed.

27.01.09.01

  • 27Compound BoratesClass
  • 27.01MiscellaneousType
  • 27.01.09— unnamed intermediate level —Group
  • 27.01.09.01Moydite-(Y)Species
CIM

10.4.5

  • 10Borates with other anionsClass
  • 10.4Borates with carbonateGroup
  • 10.4.5Moydite-(Y)Species

Literature, links & citation

Citations
  1. 1986Grice, J.D., Van Velthuizen, J.J., Dunn, P.J., Newbury, D.E., Etz, E.S., Nielsen, C.H. (1986) Moydite (Y,REE)[B(OH)4](CO3), a new mineral species from the Evans-Lou pegmatite, Quebec. The Canadian Mineralogist: 24: 665-673.
  2. 1986Grice, Joel D., Ercit, T. Scott (1986) The crystal structure of moydite. The Canadian Mineralogist, 24 (4). 675-678
  3. 1996Grew, Edward S.; Anovitz, Lawrence M. - Eds. (1996) Boron - Mineralogy, Petrology and Geochemistry. Reviews in Mineralogy Vol. 33. Mineralogical Society of America p.862
  4. 2005(2005) Moydite-(Y). Handbook of Mineralogy. Mineralogical Society of America
