Nabiasite

BaMn9(VO4)6(OH)2
IMA status
  • Approved
IMA symbol
Nbi
Also known as
  • IMA1997-050
  • Nabiasiet

Where it forms, where it's found

Geological setting

metamorphosed manganese ores.

Type locality
Plan de Labasse
  1. Nabias
  2. Aure Valley
  3. Hautes-Pyrénées
  4. Occitanie
  5. France

42.8017°, 0.3847°

5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Adamantine
Transparency
Transparent
Colour
dark red
Streak
dark yellow, almost orange
Cleavage
None Observed
Fracture
Conchoidal
Density
4.32 g/cm³

Optical

Optical type
Isotropic
Surface relief
Very high
Principal indices
n 2.025 – 2.036
UV response
None
Notes

RI calculated from Gladstone-Dale. a slight anisotropy under crossed nicols

Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation
Single index
n = 2.030

Crystallography

Crystal system
Isometric
Space group
Pa3
Cell parameters
a = 12.832(2) Å
Z
4
Type-locality form

anhedral grains up to 100 microns

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
25MnManganeseManganese954.938494.442
36.48%
8OOxygenOxygen2615.999415.974
30.69%
23VVanadiumVanadium650.942305.652
22.55%
56BaBariumBarium1137.327137.327
10.13%
1HHydrogenHydrogen21.0082.016
0.15%
Total1355.411100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1997-050
  • Nabiasiet

In other languages

German
IMA 1997-050 · Nabiasit
Italian
Nabiasite

Classification

Strunz
10th ed.

8.BF.20

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BFWith medium-sized and large cations, (OH, etc.):RO4< 0.5:1Group
  • 8.BF.20NabiasiteSpecies
Dana
8th ed.

41.09.04.01

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.09(AB)5(XO4)3ZqType
  • 41.09.04— unnamed intermediate level —Group
  • 41.09.04.01NabiasiteSpecies

Literature, links & citation

Citations
  1. 1999Brugger, Joel, Bonin, Michel, Schenk, Kurt J., Meisser, Nicolas, Berlepsch, Peter, Ragu, Alain (1999) Description and crystal structure of nabiasite, BaMn9[(V,As)O4]6(OH)2, a new mineral from the Central Pyrenees (France) European Journal of Mineralogy, 11 (5) 879-890 doi:10.1127/ejm/11/5/0879DOI: 10.1127/ejm/11/5/0879
  2. 2021(2021) Nabiasite. Handbook of Mineralogy. Mineralogical Society of America
