Nafertisite

Na3Fe2+10Ti2(Si6O17)2O2(OH)6F(H2O)2
IMA status
  • Approved
IMA symbol
Naf
Also known as
  • IMA1994-007
  • Nafertisiet

Where it forms, where it's found

Geological setting

Hyperagpaitic pegmatites. Interstitial to potassium feldspar.

Type locality
Kukisvumchorr Mt
  1. Murmansk Oblast
  2. Russia

67.7280°, 33.6664°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Silky
Colour
Dark grass-green · bronze-brown
Cleavage
Perfect

(010) and (001)

Fracture
Fibrous
Density
2.7 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 75 – 76° · 2V calc = 76°
Refractive index
1.627 – 1.693
Surface relief
High
Principal indices
nα 1.627 · nβ 1.667 · nγ 1.693
Pleochroism
Strong

X = reddish brown, Y = green, Z = dark green, Z > Y >> X

Dispersion
r > v or r < v
Extinction
Z ≈ a; Y = b; X ∧ c = 5° in obtuse angle β. Fibers have positive elongation and straight extinction.
UV response
Not fluorescent
Notes

Absorption: Z > Y >> X.

Michel-Lévy diagramhighlighted lineδ = 0.0660
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]660 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation660 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 5.358(1) Å · b = 16.204(3) Å · c = 21.976(4) Å
Cell angles
β = 94.91(1) °
Ratio a:b:c
1 : 3.024 : 4.102
Unit cell volume
1901 ų
Morphology

Fibers are 0.01-0.1 mm thick, bounded by (010) and (001) cleavages, flattened along (001), and elongate [100].

Type-locality form

Fine, fibrous (asbestiform) light-green aggregates up 5-10 mm across.

Comment

A2/m

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen4415.999703.956
39.26%
26FeIronIron1055.845558.450
31.14%
14SiSiliconSilicon1228.085337.020
18.79%
22TiTitaniumTitanium247.86795.734
5.34%
11NaSodiumSodium322.99068.970
3.85%
9FFluorineFluorine118.99818.998
1.06%
1HHydrogenHydrogen101.00810.080
0.56%
Total1793.208100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1994-007
  • Nafertisiet

In other languages

German
IMA 1994-007 · Nafertisit
Italian
nafertisite

Classification

Strunz
10th ed.

9.EH.30

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EHTransitional structures between phyllosilicate and other silicate unitsGroup
  • 9.EH.30NafertisiteSpecies

Literature, links & citation

Citations
  1. 1995Khomyakov, A. P., Ferraris, G., Ivaldi, G., Nechelyustov, G. N., Soboleva, S. V. (1995) Nafertisite Na3(Fe2+,Fe3+)6[Ti2Si12O34](O,OH)7·2H2O, a new mineral with a new type of banded silicate radical. Zapiski Vserossijskogo Mineralogicheskogo Obshchestva, 124 (6) 101-107
  2. 1996Jambor, John L., Grew, Edward S., Roberts, Andrew C. (1996) New mineral names. American Mineralogist, 81. 1513-1518
  3. 1996Ferraris, Giovanni, Ivaldi, Gabriella, Khomyakov, Alexander P., Soboleva, Svetlana V., Belluso, Elena, Pavese, Alessandrο (1996) Nafertisite, a layer titanosilicate member of a polysomatic series including mica. European Journal of Mineralogy, 8 (2) 241-249 doi:10.1127/ejm/8/2/0241 DOI: 10.1127/ejm/8/2/0241
  4. 1997Mandarino, Joseph A. (1997) Abstracts of New Mineral Descriptions. The Mineralogical Record, 28 (2) 141-145
  5. 1999Petersen, O. V., Johnsen, O., Christiansen, C. C., Robinson, G. W., Niedermayr, G. (1999) Nafertisite - Na3Fe10Ti2Si12(O,OH,F)43 - from the Nanna pegmatite, Narsaarsuup Qaava, South Greenland. Neues Jahrbuch für Mineralogie - Monatshefte, 1999. 303-310
