Narsarsukite

Na2(Ti,Fe3+)Si4(O,F)11
IMA status
  • Approved
  • Grandfathered
IMA symbol
Nar
Discovered
1900
Also known as
  • Goureit
  • Goureita
  • Goureite
  • +2 more

Where it forms, where it's found

Type locality
Narssârssuk pegmatite
  1. Narsaarsuk Plateau
  2. Igaliku
  3. Kujalleq
  4. Greenland

61.0331°, -45.3778°

34recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5 – 7/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent · Opaque
Colour
Yellow · yellowish-white · grayish-white · honey-yellow · tan · pink · greenish-yellow · green · brown · orange · colourless
Streak
White
Tenacity
brittle
Cleavage
Imperfect/Fair

(110) well developed/fair, (010) distinct

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
2.64 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.601 – 1.655
Surface relief
Moderate
Principal indices
nω 1.601 – 1.614 · nε 1.632 – 1.655
Pleochroism
Weak

O = colorless to yellow; E = colorless to honey-yellow

Michel-Lévy diagramhighlighted lineδ = 0.0360
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]360 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation360 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
#135
Cell parameters
a = 10.72(5) Å · c = 7.94(5) Å
Z
4
Morphology

Tabular, equant

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
9FFluorineFluorine1118.998208.978
32.30%
8OOxygenOxygen1115.999175.989
27.20%
14SiSiliconSilicon428.085112.340
17.36%
26FeIronIron155.84555.845
8.63%
22TiTitaniumTitanium147.86747.867
7.40%
11NaSodiumSodium222.99045.980
7.11%
Total646.999100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Goureit
  • Goureita
  • Goureite
  • Narsarsukiet
  • Unnamed (MSH UK-2)

In other languages

German
Narsarsukit
Italian
narsarsukite
Chinese
短柱石

Classification

Strunz
10th ed.

9.DJ.05

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DJInosilicates with 4-periodic double and triple chainsGroup
  • 9.DJ.05NarsarsukiteSpecies
Dana
8th ed.

70.01.02.01

  • 70Inosilicates Column or Tube StructuresClass
  • 70.01Column or Tube Structures with columnar silicate unitsType
  • 70.01.02Double crankshaft chainsGroup
  • 70.01.02.01NarsarsukiteSpecies
CIM

17.1.29

  • 17Silicates Containing other AnionsClass
  • 17.1Silicates with fluoride (not containing Al)Group
  • 17.1.29NarsarsukiteSpecies

Literature, links & citation

Citations
  1. 1901Flink, G. (1901) Part I: On the Minerals from Narsarsuk on the Firth of Tunugdliarfik in Southern Greenland. Meddelelser om Grønland, 24. 7-180
  2. 1932Goßner, B., Strunz, H. (1932) Kürzere Originalmitteilungen und Notizen: Die chemische Zusammensetzung von Narsarsukit. Zeitschrift für Kristallographie, 82 (1-6). 150-151 doi:10.1524/zkri.1932.82.1.150DOI: 10.1524/zkri.1932.82.1.150
  3. 1934Warren, B. E., Amberg, C. R. (1934) X-ray study of narsarsukite, Na2(Ti, Fe)Si4O11. American Mineralogist, 19 (11) 546-548
  4. 1934Lacroix, A. (1934) Identification d'un minéral dénommé provisoirement "gouréite". Comptes rendus de l'Académie des Sciences, Mem. No 61: 318. (as gouréite)
  5. 1935Graham, William A. P. (1935) An occurrence of narsarsukite in Montana. American Mineralogist, 20 (8) 598-601
