Nevadaite

(Cu2+,◻,Al,V3+)6Al8(PO4)8F8(OH)2 · 22H2O
IMA status
  • Approved
IMA symbol
Nev
Discovered
1992
IMA approved
2002
Also known as
  • IMA2002-035
  • Nevadaiet

Where it forms, where it's found

Geological setting

Hydrothermally altered sedimentary rocks. From the upper supergene zone. Brecciated and silicified silty carbonate rocks (jasperoid).

Type locality
Gold Quarry Mine
  1. Maggie Creek Mining Subdistrict
  2. Carlin Trend
  3. Eureka County
  4. Nevada
  5. USA

40.7914°, -116.2092°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Pale green · turquoise
Streak
Pale powder-blue
Tenacity
brittle
Cleavage
None Observed
Fracture
Conchoidal
Density
2.54 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 76° · 2V calc = 76°
Refractive index
1.54 – 1.553
Surface relief
Moderate
Principal indices
nα 1.54 · nβ 1.548 · nγ 1.553
Pleochroism
Visible

X = pale greenish blue Y = very pale greenish blue Z = blue

Notes

orientation: X = c, Y = a, Z = b

Michel-Lévy diagramhighlighted lineδ = 0.0130
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]130 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation130 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 12.123 Å · b = 18.999 Å · c = 4.961 Å
Ratio a:b:c
1 : 1.567 : 0.409
Morphology

Radiating clusters to 1 mm of prismatic crystals, occasionally covering surfaces greater than 2 cm diameter. Individual crystals are elongate on [001] with a length:width ratio of greater than 10:1 and a maximum diameter of approx. 30 mm. Also as spherules and druses.

Type-locality form

Pale green to turquoise-blue spherules and druses.

Comment

Space group P21mn.

Crystal structure

Synonyms

  • IMA2002-035
  • Nevadaiet

In other languages

German
IMA 2002-035 · Nevadait
Italian
Nevadaite

Classification

Strunz
10th ed.

8.DC.60

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DCWith only medium-sized cations, (OH, etc.):RO4 = 1:1 and < 2:1Group
  • 8.DC.60NevadaiteSpecies

Literature, links & citation

Citations
  1. 1995Jensen, Martin, Rota, Joseph C., Foord, Eugene E. (1995) The Gold Quarry Mine, Carlin-Trend, Eureka County, Nevada. The Mineralogical Record, 26 (5) 449-469
  2. 2003Grice, J.D., Ferraris, G. (2003) New minerals approved in 2002 and nomenclature modifications approved 1998-2002 by the commission on new minerals and mineral names, International Mineralogical Association. American Mineralogist: 88: 1620-1624.
  3. 2003Grice, J. D.; Ferraris, G. (2003) New minerals approved in 2002 and nomenclature modifications approved in 1998-2002 by the Commission on the New Minerals and Mineral Names, International Mineralogical Association. The Canadian Mineralogist, 41 (3). 795-802 doi:10.2113/gscanmin.41.3.795 DOI: 10.2113/gscanmin.41.3.795
  4. 2004Cooper, M. A., Hawthorne, F. C., Roberts, A. C., Foord, E. E., Erd, R. C., Evans, H. T., Jensen, M. C. (2004) Nevadaite, (Cu2+,◻, Al,V3+)6[Al8(PO4)8F8](OH)2(H2O)22, a new phosphate mineral species from the Gold Quarry Mine, Carlin, Eureka County, Nevada: description and crystal structure. The Canadian Mineralogist, 42 (3) 741-752 doi:10.2113/gscanmin.42.3.741 DOI: 10.2113/gscanmin.42.3.741
  5. 2004Mandarino, Joseph A. (2004) New minerals. The Canadian Mineralogist, 42 (6) 1901-1927 doi:10.2113/gscanmin.42.6.1901 DOI: 10.2113/gscanmin.42.6.1901
