Neyite

Ag2Cu6Pb25Bi26S68
IMA status
  • Approved
IMA symbol
Ney
Discovered
1969
Also known as
  • IMA1968-017
  • Neyiet

Where it forms, where it's found

Type locality
British Columbia Molybdenum Ltd. Mine
  1. Patsy Creek
  2. Kitsault
  3. Alice Arm
  4. Skeena Mining Division
  5. British Columbia
  6. Canada

55.4223°, -129.4206°

14recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
lead gray

A characteristic yellow, and eventually Prussian blue tarnish is developed

Tenacity
very brittle
Fracture
Conchoidal
Density
7.02 g/cm³

Optical

Optical colour
galena-white
Anisotropism
moderate: light grey, yellow-green, light reddish-brown to grey-black.
Tropism
Anisotropic
Reflectance R%
(41.3,44.5) 400, (41.6,44.8) 420, (41.8,45.0) 440, (42.1,45.2) 460, (42.3,45.3) 480, (42.4,45.0) 500, (42.2,45.1) 520, (41.9,44.8) 540, (41.6,44.5) 560, (41.4,44.4) 580, (41.2,44.5) 600, (41.0,44.6) 620, (40.7,44.6) 640, (40.4,44.5) 660, (40.2,44.3) 680, (39.9,44.1) 700
Reflected-light panel
41.4 %anisotropic · dual curve
Specimen sRGB 227, 160, 89
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
moderate: light grey, yellow-green, light reddish-brown to grey-black.
Reflected colour
galena-white

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 37.527(6) Å · b = 4.0705(6) Å · c = 43.701(7) Å
Cell angles
β = 108.801(2) °
Ratio a:b:c
1 : 0.108 : 1.165
Z
4
Type-locality form

Intimately intergrown with quartz

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth26208.9805433.480
40.58%
82PbLeadLead25207.2005180.000
38.68%
16SSulfurSulfur6832.0602180.080
16.28%
29CuCopperCopper663.546381.276
2.85%
47AgSilverSilver2107.868215.736
1.61%
Total13390.572100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1968-017
  • Neyiet

In other languages

German
IMA 1968-017 · Neyit
Italian
Neyite

Classification

Strunz
10th ed.

2.JB.25i

  • 2Sulfides and SulfosaltsClass
  • 2.JSulfosalts of PbS archetypeDivision
  • 2.JBGalena derivatives, with PbGroup
  • 2.JB.25iNeyiteSpecies
Dana
8th ed.

03.05.01.01

  • 03SulfosaltsClass
  • 03.052.5 < ø < 3Type
  • 03.05.01— unnamed intermediate level —Group
  • 03.05.01.01NeyiteSpecies
CIM

5.7.42

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.7Sulpharsenites etc. of Pb and other metalsGroup
  • 5.7.42NeyiteSpecies

Literature, links & citation

Citations
  1. 1969Drummond, A.D., Trotter, J., Thompson, R.M. and Gower, J.A. (1969): Neyite, a new sulphosalt from Alice Arm, British Columbia. The Canadian Mineralogist: 10: 90-96. https://rruff.info/rruff_1.0/uploads/CM10_90.pdf
  2. 2001Makovicky, Emil, Balić-Žunić, Tonči, Topa, Dan (2001) The crystal structure of neyite, Ag2Cu6Pb25Bi26S68. The Canadian Mineralogist, 39 (5) 1365-1376 doi:10.2113/gscanmin.39.5.1365 DOI: 10.2113/gscanmin.39.5.1365
  3. 2005(2005) Neyite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2016Ciobanu, Cristiana; Cook, Nigel; Maunders, Christian; Wade, Benjamin; Ehrig, Kathy (2016) Focused Ion Beam and Advanced Electron Microscopy for Minerals: Insights and Outlook from Bismuth Sulphosalts. Minerals, 6 (4). 112 doi:10.3390/min6040112DOI: 10.3390/min6040112
